Large Capacity Flour Sieve Food Processing With CE

Xinxiang Gaofu Machinery Co., Ltd. Gold Verified Supplier
5Yrs
Large Capacity Flour Sieve Food Processing With CE thumbnail-1
Large Capacity Flour Sieve Food Processing With CE thumbnail-2
Large Capacity Flour Sieve Food Processing With CE photo-1
Large Capacity Flour Sieve Food Processing With CE photo-2
US$ 2,500 - 2,600 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
GAOFU
Model Number:
DZ-1000
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin / Shanghai / Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name GAOFU
Model Number DZ-1000
Type Grain Processing Equipment
After-sales Service Provided Engineers available to service machinery overseas

Large Capacity  flour sieve food processing with CE





Large Capacity flour sieve food processing with CE
When your product including impurity, and the impurity content is not more than 10%, it will best suitable for DZ flour sieve.



 Special structure design :



 Sorting machine use two unbalanced-weight gyratory motors mounted on opposing exterior sidewalls of the unit (instead of one motor positioned beneath the screening chamber), reducing minimum height requirements significantly.





  How many apertures is it suitable  ??



 This innovation also enables the bottom outlet to be located directly below the top inlet, allowing material to fall vertically through the screen at high rates. Available from 600mm.800mm.1000mm and 1200mm in diameter.





The flour sieve 'customer :





 Large Capacity flour sieve food processing with CE



Large Capacity flour sieve food processing with CE







Features of flour sieve:



(1). Compact, light weight, mobility,

(2). Low noise and pollution,

(3). Less energy consumption and easy installation.

(4). The machine outlet can be connected to any direction. Sieved material can be discharged straight away, suitable for automated operation.

(5). No blockage on screen, high efficiency, applicable for 400 mesh or finer.

Introduction

    .

Daily maintenance:



1. before running

   (1) To check coarse mesh and fine mesh if there is damage

   (2) Each group clamps is locking.

2. Running

   (1) Notice any abnormal noises

   (2) Electric current is stable

   (3) Whether the vibration is abnormal.

3. after running

   (1) After used clean up the vibration every time

   (2) To inspect regularly the coarse mesh, fine mesh and the spring if there are fatigue and damage

   (3) Whether each part of the vibrating body caused damage due to vibration.

   (4) Need to add the site to be the lubricating oil



Technical parameters



Model

Power (kw)

Motor speed (r/min)

Sieve diameter (mm)

Dimension(mm)

Wight(kg)

SZS-600

0.18

1450

580

1000*600*550

200

SZS-800

0.25

1450

780

1100*800*600

250

SZS-1000

0.55

1450

960

1280*1000*700

330

SZS-1200

0.75

1450

1160

1550*1200*750

400

DZ-1500

1.5

1450

1460

1850*1500*900

750



 Note:

1. Material: SUS 304 / Q235A / 316 L.

2. Voltage: 380V /400V.

3. Voltage: 380V /400V, Frequency:50 / 60 HZ.

4. If the specification or appearance has changed, we will not notify additionally.







Packaging & Shipping

 Large Capacity flour sieve food processing with CE

Large Capacity flour sieve food processing with CE

Large Capacity flour sieve food processing with CE



Our service

Before Sales:

1> Accept customer consultation, according to the customer demand; determine the scale of factory management, providing solutions.

2> For customer training and technical personnel;

3> According to customer request, design and manufacture products;

4> The company sent engineering and technical personnel to the user scene, planning for the optimal design of the flow field, and the solutions;

5> For customers in relevant technical documents.

Medium-sales:

1> Acceptance of the product;

2> Assist client protocol construction scheme;

After-sales:

1> On-site training personnel;

2> Appoint special after-sale service staff, arrived at the scene guide clients installation and commissioning;

3> Regular visit customer, consult with the customer feedback, come true with the customer's two-way communication.
