Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve

Xinxiang Gaofu Machinery Co., Ltd. Gold Verified Supplier
5Yrs
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve thumbnail-1
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve thumbnail-2
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve thumbnail-3
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve thumbnail-4
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve thumbnail-5
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve thumbnail-6
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve photo-1
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve photo-2
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve photo-3
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve photo-4
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve photo-5
Explosion-Proof Motor Separator Rotary Vibrating Sieve Machine and Vibro Sieve photo-6
US$ 2,000 - 2,510 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Separating Plant
Product Type:
Other, medicine powder process equipment
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin / Shanghai / Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Separating Plant
Product Type Other, medicine powder process equipment
Place of Origin Henan, China
Brand Name Gaofu
Model Number S49-1000-2 Layers
Voltage 110v,240v ,380v 415v and others
Power(W) 1.5kw
Weight 458kg, 430kg
Dimension(L*W*H) 1000*1210*1345mm
Certification ISO,BV,SGS ,CE GMP and others
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

xplosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve





Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve

 Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve



1. Model : S49-1000-2S

2. Diameter : 1000mm

3. Overall dimensions :1000*1210*1325mm

4. Material : SUS304 Stainless steel or 316L

5. Layer : two layers

6. Explosion Proof and power : BxdⅡBT4 ,  ⅡP55 ; 1.5KW

7. Certificate : SGS , BV ,CE , ISO ,GMP and others you need .





 Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve





 1. Application :

 Pellets;harmaceutical Intermediates;  bulk drug; ;Bulk Pharmaceutics

 2. Screening layers :

Pharmaceutical intermediates usually use one layer ; Bulk drug useally use two layers and Pellets usually use three layers or more ;

Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve

3.     Screening purpose : grading or impurity and filtering ;

4.     Screening capacity :600-1000kg ;

Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve

Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve

1. By changing the eccentric block’s included angle (the upper and down), the motion  material moves on the mesh ill be changed. So that the screening target will be realized.

2. By means of a hammer (unbalance hammer) mounted along the motor shaft, S49 Series 3-D rotary shaker machine convert the rotation of the motor into a 3-D movement, i.e. horizontal, vertical and inclined movement, and then the 3-D movement is transferred to the screen surface, which leads to an involute movement of the materials on the screen surface

3. Changing different agles ,  different materials for screening : powder , granule and mucilage .

 Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve



♦ Small volume with easy moving

♦ High efficiency with compact structure

♦ Easy operation and maintenance

♦ Long screen life, easy&quick screen cloth exchange

♦ Equipped with anti-blinding device(bouncing balls), as well as dust-proof cover

♦ ISO9001:2008, CE and Food standard certification





Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve





Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve









Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve

Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve

Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve
 Explosion-Proof Motor separator rotary vibrating sieve machine and vibro sieve
