Tunnel type industrial hot air apricot belt dryer
Item | Description |
Item Name | BODA five-layer hot air apricot belt dryer |
Type | BDHD-F-12 |
Overall Dimension | 12000×2000×2100(h)mm |
Drying Chamber | An independent hot air circulation unit in every two meters |
Transmission | Chain Drive |
Mesh Belt Specification | W=1800, mesh hole size 10×16mm (Different hole size belt will be used according to materials size), mesh diameter 1.2mm, Material SUS304; Roller 12mm round steel, Interval 150mm, Material SUS304; Chain interval 38.1mm, roller diameter 22.23mm, thickness 3mm, Material 201 |
Mesh layer | Five layers |
Motor Power | 3kw stepless variable speed motor + frequency control |
Transmission Speed Range | 0.3~5m/min,(time 30~300min) |
Fan | DLF4.5C low noise centrifugal fan |
Fan Parameter | 4kw×6 sets, air volume 12500-6500m³/h,motor power 4kw, rpm 900 r/min, full pressure 830Pa |
Heating Source | Steam exchanging heat, steam pressure 0.4~0.6MPa |
Heat Exchanger | SRZ5×5D×6 sets, stainless steel composite aluminum fin tube, heat exchange area 120 square meter |
Steam Consumption | 600~800kg/h |
Input Power | ≤35kw |
Drying Temperature | 0~80℃,temperature tolerances ±3℃ |
Heating Mode | Hot air circulation heating and flow through heating |
Control System | PLC control, touch screen, automatic temperature control, transmission control, air volume control, video monitoring, fault display etc |
Feeding | Automatic distribute material,evenly distribution,thickness adjustable |
Feeding Port Size | H=3500mm,W=2000mm |
Discharging Port Size | H=600mm,W=2000mm |
Door | Stainless steel appearance |
Working Voltage | 380V 3 phase |
Relative Humidity( ℃) | ≤85% |
Environment Temperature ( ℃) | Seasonal Temperature |
Temperature Requirement | Should be no excessive corrosive gas,no inflammable and explosive gas around |
Site requirements | Smooth and flat cement floor |
Usage:
The hot air apricot dryer is used for drying apricot, prune, plum, banana, orange, apple, kiwi, papaya and all kinds of fruits, vegetables, spices, etc.
It is designed for mass process quantity to achieve automatic continuous production. Single layer or multi layer belt dryer will be customized according to your requirements.
Packing & Shipping:
1 set of apricot hot air belt dryer is fit for a 40GP.
Wooden pallet or other packing will be used, supported with soft packing to prevent shift of apricot drying machine in container.
BODA provides a full range of services and technical support for industrial apricot hot air belt drying machine. The services include custom installations, preventive equipment maintenance, equipment upgrades and modifications and drying system repair.
