Home > Products > Conti microwave dryer > green tea microwave tunnel dryer and sterilizer
green tea microwave tunnel dryer and sterilizer
- 400 Set / Sets per Month
- Qingdao Shanghai Ningbo other China seaports
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | BODA |
Model Number: | BDMD-F-P-20 | Type: | Other, dryer and sterilizer | Voltage: | 380V |
Power(W): | 20kw | Weight: | 2000kg | Dimension(L*W*H): | 8x1.1x1.7m |
Certification: | CE, ISO | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
green tea microwave tunnel dryer and sterilizer
Product Description:
Model number | BDMD- F-P-20 |
Description | BODA green tea microwave tunnel dryer and sterilizer |
Microwave frequency (MHz) | 2450±50 |
Input voltage | 380V, 50Hz |
Microwave power(KW) | Microwave power(KW) |
Chamber material | Stainless steel |
Chamber color | Silver-white |
Conveyor belt | PTFE |
Dryer dimension(L*W*H)(mm) | 8.0x1.1x1.7 |
Weight (KG) | 2000 |
Microwave leakage limit(mW/cm2) | 1 mW/cm2 |
Relative humidity(℃) | ≤85% |
Ambient temperature(℃) | Normal temperature |
Environment requirement | No excessive corrosive gas, no inflammable, explosive gas |
Usage:
The green tea microwave drying and sterilization machine is used for drying and sterilizing all kinds of green tea, black tea, CTC tea, etc.
Advantage:
Advantage of microwave green teas dryer and sterilizer
Teas microwave dryer and microwave sterilizer has a number of quantitative and qualitative advantages over conventional drying and sterilization techniques that make its adoption a serious proposition. One main advantage is the place where the heat is generated, namely the product itself. Because of this, the effect of small heat conductivities or heat transfer coefficients does not play such an important role. Therefore, larger pieces can be heated and sterilized in a shorter time and with a more even temperature distribution. These advantages often yield an increased production and high efficiency.
- Energy saving 40%-80%
- Drying and sterilization speed 5times quicker
- Reduced CO2 emissions
- Increased manufacturing efficiency and throughput
- Drying temperature and sterilization temperature adjustable
- Suitable for drying and sterilizing tea leaves and tea powders
Packing & Shipping:
Wooden packing for each set of green tea industrial microwave dryer and sterilization machine
Soft packing is supplied.
Our Services:
BODA provides a full range of services and technical support for industrial microwave drying and sterilization systems. The services include custom installations, preventive equipment maintenance, equipment upgrades and modifications and microwave system repair.
Company Information:
FAQ:
1. What is Microwave?
Microwaves are a form of electromagnetic energy with frequencies between 300 MHz and 300 GHz, generated by magnetrons under the combined force of an electric and a magnetic field perpendicular to each other.
2. What is the advantage of Microwave dryer and sterilizer compare to Conventional dryer and sterilizer?
Conventional dryer and sterilizer is a surface heating method, which is not only slow, but also non-uniform with the surfaces, edges and corners being much dried than the inside of the material. The imperfect heating will cause product rejections, waste energy and extend process time.
Microwave tea dryer and sterilizer is a direct method of drying and sterilization. Energy is transferred through the material electro-magnetically, not as a thermal heat flux. Therefore, the rate of heating is not limited, the uniformity of heat distribution is greatly improved and chilli drying time and sterilization is reduced.
3. How about safety?
Using scientific structure and patented suppression system, BODA industrial microwave dryer poses no threat of electromagnetic radiation to the health and safety of equipment operators.
4.What about maintenance?
In addition to downtime for cleaning and inspection, conventional dryers and heat exchangers need periodic servicing with an expensive inventory of parts and a highly trained labor force. For microwave dryer, the only part that requires maintenance is the magnetron. In the event of a malfunction or misuse through incorrect operation, this can easily be replaced in less than thirty minutes. Generally, BODA recommends that the magnetron of industrial microwave dryer be replaced annually or after 8,000 hours of operation, whichever is sooner.
Contact:
You are here: Home >> Conti Dryer >> green tea microwave tunnel dryer and sterilizer
Contact Us
- Henan Boda Microwave Equipment Co., Ltd.
- Contact namePumpkin sister huang
- Phone86-0371-61171711
- AddressBuilding 18, No.1 Cuizhu Street, Zhengzhou High & New Technology Industries Development Zone Zhengzhou,Henan
