100kw Microwave Continuous Dryer
Machine Features
1. Patent core components manufactured by BODA, reliable and stable performance.
2. Whole machine case are made with stainless steel of food grade, easy for cleaning and with smooth appearance.
3. Interface operation and on-site monitoring, PLC auto-control system, all the datum can be saved, output and printed etc.
4. Working parameters can be setted easily according to different drying demand according to different materials.
5. Microwave power stepless adjustable, conveyor speed adjustable, temperature and humidity are intelligent controled.
6. Machine start, power off automatically, drying material and microwave generator can start and off synchronously.
7. Adopting Noncontact infrared measuring temperature technology, ensure the accuracy of temperature control easily.
8. Material loading and unloading operated easily, easy for connecting to other process, can achieve automation flow operation easily.
9. BODA unique ventilation system can speed up moisture removal speed, raise drying efficiency.
10. Conveyor auto deviationchecking device can keep the machine running smoothly and steadily.
Model |
Working Frequency (MHZ) |
Output power (kw) |
Microwave leakage (mW/cm2)
|
External Dimension (m) |
Installation Area (m) |
Gross Weight (Kg) |
Output of Drying (kg/h) |
Output of Sterilization (kg/h) |
BDMD-F-P-15 |
2450±50 |
15 |
≤1 |
7.0x1.1x1.8 |
9.0x3.5x2.5 |
1600 |
40-75 |
150-180 |
BDMD-F-P-20 |
2450±50 |
20 |
≤1 |
8.0x1.1x1.8 |
10x3.5x2.5 |
2000 |
50-120 |
200-250 |
BDMD-F-P-30 |
2450±50 |
30 |
≤1 |
9.0x1.1x1.8 |
11x3.5x2.5 |
2400 |
65-160 |
300-400 |
BDMD-F-P-40 |
2450±50 |
40 |
≤1 |
10x1.1x1.8 |
12x3.5x2.5 |
2800 |
100-240 |
400-500 |
BDMD-F-P-50 |
2450±50 |
50 |
≤1 |
10x1.1x1.8 |
12x3.5x2.5 |
3200 |
120-300 |
500-600 |
BDMD-F-P-80 |
2450±50 |
80 |
≤1 |
13x1.1x1.8 |
15x3.5x2.5 |
5000 |
200-480 |
800-900 |
BDMD-F-P-100 |
2450±50 |
100 |
≤1 |
15x1.1x1.8 |
17x3.5x2.5 |
6000 |
240-600 |
1000-1200 |
100kw Microwave Continuous Dryer
