Specifications
High purity tantalum vertical melted plate1.High quality
2.Vergin material
3.ISO9001:2008
4.Fastdelivery
High purity tantalum vertical melted plate
Chemical composition
| Chemical composition | ||||||||||||
| Chemical composition,max | ||||||||||||
| Grade | Fe | Si | Ni | W | Mo | Ti | Nb | O | C | H | N | Ta |
| Ta1 | 0.005 | 0.005 | 0.005 | 0.005 | 0.002 | 0.002 | 0.005 | 0.02 | 0.004 | 0.002 | 0.005 | balance |
| Ta2 | 0.005 | 0.005 | 0.005 | 0.005 | 0.002 | 0.002 | 0.1 | 0.03 | 0.01 | 0.002 | 0.01 | balance |
| FTa1 | 0.005 | 0.005 | 0.005 | 0.005 | 0.002 | 0.002 | 0.005 | 0.02 | 0.003 | 0.002 | 0.005 | balance |
| FTa2 | 0.01 | 0.03 | 0.01 | 0.005 | 0.002 | 0.002 | 0.1 | 0.035 | 0.003 | 0.002 | 0.01 | balance |
| Remark | Ta1 and Ta2 are made of ingot blanks,FTa1 and FTa2 are made of vertical melted bars | |||||||||||
Grade
Grade: RO5200, RO5400, RO5252, RO5255
Size: Dia50 to 200mm× random length
The Special sizes are available upon customers requirement.
Purity :> =99.95% .
Characteristic:
Melting Point: 2996 DC.
Boiling Point: 5425 DC .
Density: 16.6g/cm3 .
High quality, workability.
Product Feature: High melting point, High-density, high temperature oxidation resistance, long service life, resistance to corrosion.
Mechanical properties
Grade(UNS) |
Annealed |
||
Tensile strength min, psi (MPa) |
Yield strength min,psi (MPa)(2%) |
Elongation min, % (1 inch gage length) |
|
Pure Ta (RO5200, RO5400) |
30000 (207) |
20000 (138) |
20 |
Ta-10W (RO5255) |
70000 (482) |
60000 (414) |
15 |
Ta-2.5W (RO5252) |
40000 (276) |
30000 (207) |
20 |
Ta-40Nb (RO5240) |
35000 (241) |
20000 (138) |
25 |
Dimensions
|
Width (mm) |
Length (mm) |
|
Foil |
0.01-0.09 |
30-150 |
>200 |
Sheet |
0.1-0.5 |
30- 609.6 |
30-1000 |
Board |
0.5-10 |
50-1000 |
50-2000 |
Purity: >=99.95% | |||
