Specifications
To provide a machine which is suitable for any use, we have produced a wide variety of wire ropesteel rope wire product for unic crane
made in japan
Since wear resistance, fatigue resistance, model-proof collapse nature, relation-proof nature, etc. are required of the wire rope for cranes, the rope is used from the balance.
The main machines used
Rough terrain crane,The crane for equipment,Tower crane,Crawler crane,Hoist crane,Various winches,The lift for construction,Gondola,Piledriver,Deck crane,Glove bucket
IWRC F6×Fi(29),IWRC L6×WS(31),IWRC L6×WS(36)
Classification |
Product Name | Constitution-Classification | Cross-sectional view |
D/d | Torque efficient | Real Goods | Breaking load |
| Flame-retardant rope | Flex | IWRC F6×Fi(29 )C-species | 16 | 0.45~0.55 | 10φ 16φ | 1.10 | |
| Hyper | IWRC H6×Fi(29) C-species | 16 | 0.4~0.5 | 6φ 10φ | 1.10 | ||
| Long | IWRC L6×WS(26)C-species | 16 | 0.55 | 8φ 10φ 20φ | 1.08 | ||
| Long | IWRC L6×WS(31)C-species | 16 | 0.6 | 10~20φ | 1.10 | ||
| long | IWRC L6×WS(36)C-species | 16 | 0.65 | 10φ 16φ | 1.10 | ||
| 7*P-7 6×WS(36)specified species | 16 | 0.65 | 16φ | 1.22 |
In recent years, mobile cranes are becoming degree Positive, entangled in this multi-hook has become more likely to occur. Order to improve your work, our company has a good reputation to develop superior to flame-retardant 'flex rope'.
The main winding and auxiliary winding of a mobile crane is 'flex rope' easier to handle better I is ideal for flame resistance.
Features flex rope
1,It is excellent in flame retardancy.
And to prevent the rotation processed by using a special pitch, involving much less in this hanging compared to the same components, it is excellent in workability and stability.
2,High breaking load.
Are produced in standard high breaking than standard JIS, it is applicable in a wide range of models.
3,I have excellent fatigue resistance.
Has become more parallel, we have to prevent secondary fatigue due to bending.
4×F(30),4×F(39)
Classification |
Product Name | Constitution-Classification | Cross-sectional view |
D/d | Torque efficient | Real Goods | Breaking load |
| Rotation of the non-rope | NACK Force | 4×F(39)C-species | 20 | 0.1~0.2 | 8~18φ | 1.03 |
Please use the 'NACK force' if you are a non-rotation of the more demanding, such as the construction crane in about exaltation.
In working with the crane, entangled in this multi-hook, the rotation of the load hanging and suspended one reduces work efficiency as extremely uplifting.
In order to solve the problems such, the Company has a good reputation we developed a four strand rope 'NACK Force', which is a paramount concern of non-rotation.
Features NACK Force (Rotation of the non-rope)
1, I have excellent non-rotation.
And to prevent the rotation by applying special processing, it is unlikely that rope tangled with each other in use.
I do not rotate to almost suspended even when you use it one also suspended.
2, Difficult to crumble form.
We has characteristics compared to rope for other configurations of non-rotation, special processing is performed, even under the action of squeezing the sheave or the like, there is hardly collapsed shape.
3, I have excellent wear resistance.
There is a characteristic that has become a smooth surface, the contact surface drum, and the like sieve is large, it is difficult to wear.
4, I have excellent fatigue resistance.
Has become more parallel, we have to prevent secondary fatigue due to bending.
IWRC6×P-Fi(25),IWRC6×P-WS(26)
Classification |
Product Name | Constitution-Classification | Cross-sectional view |
D/d | Torque efficient | Real Goods | Breaking load |
| Deformed wire rope | Power | IWRC 6×P-WS(31)C-species | 16 | 0.8 | 10~16φ | 1.23 |
Harsh conditions frequently used large load relief, such as search, it is recommended that you use the most important wear resistance of the 'power rope'.
Ropes are used in various industrial machines than parallel. Developed a strand rope 'power rope' line variant with Testimonials by things of high quality, with an emphasis on the highest wear resistance In addition, the Company has earned us a good reputation.
Characteristics of the strand rope 'power rope' deformed wire
1,I have excellent wear resistance.
The contact surface of the contact surface has become smooth surface, such as a sieve for a large contact area with the smaller contact surface pressure of each strand are dispersed, we have a strong frictional characteristics.
2,Difficult to crumble form.
For each wire is in contact with the surface, is also less likely to occur due to loss of shape in ironing less internal wear, and also less likely to occur when lifting wire.
3,High breaking load.
Effective area is larger than that of the normal rope the same configuration, is a potent Too high breaking load.
4,I have excellent fatigue resistance.
For each wire to the contact surface, and contact is made between the strand line, I have the property of being resistant to repeated bending fatigue.
5,I do not damage the drum, sheaves, and rollers.
A large contact surface for a smooth surface to reduce the pain of the sheave.
6,Flexibility
While slightly harder than the rope so the same configuration between wires are in contact with the surface, there is no problem on the work.
Other products
Classification |
Product Name | Constitution-Classification | Cross-sectional view |
D/d | Torque efficient | Real Goods | Breaking load |
| General rope | IWRC 6×Fi(29)B-species | 16 | 1 | 6~24φ | 1 | ||
| Other | Short | IWRC S6×Fi(29) Specified species | 16 | 0.7~0.8 | 14~20φ | 1.10 |
