1000kgs permanent magnetic lifter with trade assurance
permanent magnetic lifter specifications:
permanent magnetic lifter has strong magnetic path produced by NdFeB magnet. On and off magnetic path is controlled by turning the manual handle. The lifters have the features of strong attraction, smaller volume, lighter weight, powerful lifting effort, easy and safe to operate, long-period effort and without power supply. They are been used to lift and transport the steel and iron for factories, docks, ware houses, and so on.
permanent magnetic lifter material: NdFeB Magnet, Neodymium Magnet, Permanent Magnet, Rare-earth Magnet
Lifting weight:100kg,300kg,500kg,1000kg,2000kg,3000kg
pulling-out force:3 times,3.5 times
permanent magnetic lifter widely used in machining, mould producing industry.
Using high-performance permanent magnetic materials, Strong in magnetic suction, patent circuit design, remanence almost zero.
High safety factor, maximal breakway force is 3.5 times rated lifting power.
Handle switches with safety twist, easy for Single-hand operation, more safety and convenience.
V style design at the bottom of lifter,can lift opposite round steel or steel board.
permanent magnetic lifter without electricity, magnetic lasting popularity, more safety on using, aside may operated at open country.
Model | Rarde Lifting (KG) | Boundary dimension(MM) | MAX Lift | Net Weight | ||||
steel plate | cylidrical workpiece | L | B | H | R | KG | KG | |
PML-1 | 100 | 50 | 95 | 77 | 80 | 155 | 350 | 3.5 |
PML-3 | 300 | 150 | 163 | 105 | 110 | 185 | 1050 | 11.5 |
PML-4 | 400 | 200 | 201 | 115 | 115 | 210 | 1400 | 18.2 |
PML-6 | 600 | 300 | 221 | 120 | 125 | 235 | 2100 | 25 |
PML-10 | 1000 | 500 | 295 | 145 | 152 | 265 | 3500 | 48 |
PML-15 | 1500 | 750 | 313 | 145 | 152 | 350 | 5000 | 55 |
PML-20 | 2000 | 1000 | 360 | 170 | 178 | 426 | 6000 | 90 |
PML-30 | 3000 | 1500 | 460 | 180 | 186 | 520 | 9000 | 120 |
PML-50 | 5000 | 2500 | 660 | 260 | 280 | 650 | 15000 | 240 |
PML-100 | 10000 | 5000 | 870 | 260 | 300 | 750 | 30000 | 500 |
1.The Mini Order?
We can accept only one piece.
2.About sample.
The buyer should offer the cost and freight, if the quantity is big then can turn back all of it after placing the order.
3.About payment.
100% TT as deposite, if amount more than 5000usd.
Or 30%TT as deposite, balance after B/L copy.
4.How long does it take to receive my order?
About 15 Days from we get the down payment, 7 days for sample order.
5.What is the information should I provide when inquiry?
a. How many will I want to buy?
b. How much is the maximum capacity of the permanent magnetic lifter ?
6.How will my order shipped?
Usually shipped by sea, small order or urget order we can send you by Air or DHL,UPS or Fedex, after received your agreement.
