220v 12 meters 250kg electric hoist
- 1000 Set / Sets per Month
- QINGDAO
- Credit Card
- Explosion proof electric hoist with curved rail on top of LNG storage tank
- Explosion proof electric hoist with curved rail on top of LNG storage tank
- Low Head Room Wire Rope Electric Hoist
- Stage Chain Hoist Fashion Mini Cool Design
- Wholesale manual hand operated hoist HSZ chain pulley block hoist for factory
- manual door frame pallet stacker
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | JNDO |
Model Number: | PA | Usage: | Construction Hoist | Power Source: | Electric |
Sling Type: | Wire Rope | Maximum Lifting Weight: | 1200kgs | Maximum Lifting Height: | 12M |
Lift Speed: | 10M | Certification: | CE | Warranty: | 1 Year |
After-sales Service Provided: | No overseas service provided |
Product Description
1. 220v 12 meters 250kg electric hoist key specifications/features :
• The emergency stop switch
• Upper limit function
• Thermal protection terminal
• Protection class IP54
• Insulation class B
• Group of mechanisms M1
• Work Duty: S3-25%-10min
• Rated Volt: 220/230V ~ 50Hz
• Rated Current: 2.0A
• Input Power: 480W
• Lifting Weight: 100-600kg (Single-line), 200-1200kg (Double-line)
• Lifting Height: 12m (Single-line), 6m (Double-line)
• Lifting Speed: 10m/min (Single-line), 5 m/min (Double-line)
• Diameter of wire rope: 3.0mm
• Tensile strength of wire rope ≥ 1870N/mm2
2. 220v 12 meters 250kg electric hoist logistic Information:
• Packing pattern: 1pc per color inner box, 2pcs per master carton
• Packing Dimension: 44*38*20 cm
• G.W./N.W.: 24/22kg
• Qty /1x20’FCL: 1650pcs
3.payment Details:
• Payment terms: T/T
• MOQ: 200 PCS Min
4.delivery Details:
• FOB Ports: Qingdao port
• Lead time: 10 days
5.harmonization System (HS) Code:
• 8425 1100
6. technical parameters of 220v 12 meters 250kg electric hoist :
Model | PA200 | PA250 | PA400 | PA500 | PA600 | PA800 | PA1000 |
Rated Volt(V) | 230-50hz S3 20% 10 min | ||||||
Input Power (w) | 450 | 500 | 750 | 900 | 1050 | 1300 | 1600 |
Rate Lifting(kg) | 100/200 | 125/250 | 200/400 | 250/500 | 300/600 | 400/800 | 500/1000 |
Lifting height(m) | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 |
Lifting speed(m/min) | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 |
packing dimensions(cm) | 44*38*20 | 44*37*25 | 44*37*25 | 44*37*25 | 53*45*19 | 53*28*35 | 53*28*35 |
G.W/N.W | 24/22 | 25/24 | 25/33 | 36/34 | 41/38 | 38/36 | 40/38 |
quan/ctn(pcs) | 2 | 2 | 2 | 2 | 2 | 1 | 1 |
1.The Mini Order of 250kg electric hoist ?
We can accept only one piece.
2.About sample.
The buyer should offer the cost and freight, if the quantity is big then can turn back all of it after placing the order.
3.About payment.
100% TT as deposite, if amount more than 5000usd.
Or 30%TT as deposite, balance after B/L copy.
4.How long does it take to receive my 250kg electric hoist order?
About 15 Days from we get the down payment, 7 days for sample order.
5.What is the information should I provide when inquiry 250kg electric hoist?
a. How many quantity will I want to buy?
b. How much is the maximum lifting weight of the hoist?
c. Which one is my need? fixed or moved by trolley?
6.How will my order shipped?
Usually shipped by sea, small order or urget order we can send you by Air or DHL,UPS or Fedex, after received your agreement.
