construction safety equipment electric wire rope motor hoist

construction safety equipment electric wire rope motor hoist

Key Specifications/Features:

• Comply with EN-11492-2 standard and patent design

• CE/GS/EMC/RoHS approval

• Upper and lower limit function

• Anti-reverse winding function

• The emergency stop switch

• Thermal protection terminal

• Protection class IP54

• Insulation class B

• Group of mechanisms M1

• Work Duty: S3-20%-10min

• Rated Volt: 220/230V ~ 50Hz

• Rated Current: 2.2A

• Input Power: 500W

• Lifting Weight: 125kg(Single-line), 250kg(Double-line)

• Lifting Height: 18m(Single-line), 9m(Double-line)

• Lifting Speed: 8m/min(Single-line), 4m/min(Double-line)

• Diameter of wire rope: 3.0mm

• Tensile strength of wire rope : 1870N/mm²

   Primary Competitive Advantages:

• Safety Approval

• OEM Capability

• Production Capacity

• Reliability and Reputation

• Price and Service

    Logistic Information:

• Packing pattern: 1pc per color inner box, 2pcs per master carton

• Packing Dimension: 46.5x36.5x16cm

• G.W./N.W.: 22/21kg

• Qty /1x20’FCL: 1700pcs

   Payment Details:

• Payment terms: L/C at sight or T/T

• MOQ:10SET

  Delivery Details:

• FOB Ports: QINGDAO port

• Lead time: 30 to 50 days

Welcome to contact us! Believe we will be your best choice!
