1 ton 2 ton 10 ton wire rope electric hoist crane lifting electric hoist
High quality material:
1.Electrical equipment:Schneider Control box material:Q235B
2.Motor:Nanjing special electric
3.Bearing:Ha‘erbin Bearing
4.Gear:20Chromium manganese titanium
5.Hook:40 chrimium forge
6.Wire rope:Guizhou Julong limited liability company
7.Transmission shaft:45#quenched and tempered steel
8.Cover and coiling block:thicken steel plate
wire rope electric hoist Introduction:
wire rope electric hoist is a kind of small-lifting equipment, it can be mounted on single beam overhead crane, gantry cranes, jib type CD1 MD1 electric wire rope hoist as only one normal speed which can satisfy normal application. It is widely used in factories, mines, harbours, warehouses, cargo storage area and shops, essentially in raising working efficiency and improving working conditions.
1. wire rope electric hoist are improved ones on the basis of the original CD and MD .
2. Tight structure ,smart body,safety and reliability,commomused partsstrong lifting capacity, easy maintance.
3. The hoists exists in form of stationary style and crab-style.
4. The products are widely at industrial ore enterprises ,railway,harbors,warehouses and materials sites etc.
5. Working environment:no fire,no explosive danger ,no corrosive media and no dirt exist.
6. Working temperature:-25°C~+40°C ,Wetness is less than 85%.
Motor |
Hoist Motor is a taper type rotor motor with braking; it is of the best quality motors, it has bigger torque, so it can be adapted to moving frequently, the Maximum torque is 2.4-3 times than the rated torque. |
Gear Box |
Hoist Gear Box has specially treated gears for high wear resistance. Each Geared Shaft assembly is supported on ball or roller bearings, to ensure smooth, low-friction operation. |
Wire Rope |
Hoisting rope comply with the exporting standards. The leading rope taken by the Drum does not slip sideways when slack. The factor of safety, on the nominal breaking strength of the rope is six. |
Rope Drum |
Grooved Drum, seamless pipe of adequate length to be wounded in one layer and to provide proper support for the rope to minimize abrasive wear is provided. Drum Shaft resolves on Ball Bearings for ensuring smooth running. |
Electric apparatus controlling system |
Model CD1 or MD1 is composed of the contactor box, controlling switch, cut-off limiter. The working voltage of controlling switch is 380V, 36V or 24V (safety voltage). |
Rope Guide |
Rope Guide is in two halves, ensuring easy accessibility. It encircles the Drum completely so that the rope may not uncoil even when the Hoist is in unloaded condition. The rope guides of our company is thicken and dilated, so that it is not easy to be damaged.
|
Hook |
The hook block is tested to 150 % of full load before assembly. The rope sheaves are fully guarded with protective steel casting. All sheaves rotate on ball bearing. The pulley is thicken and dilated than domestic common |
7. 380v/50Hz/3Phases
8. Mainly consists 3 parts:lifting mechanism ,traveling mechanism and electrical equipment
9. With slight modification, it also can be use as a which.
wire rope electric hoist is assembled by several parts:
Model |
0.25TON |
0.5TON |
1TON |
2TON |
3TON |
5TON |
10TON |
Capacity ton |
0.25 |
0.5 |
1 |
2 |
3 |
5 |
10 |
Standard Lift m |
3.9 |
6-12 |
6-30 |
6-30 |
6-30 |
6-30 |
6-30 |
Lifting Height m/min |
88/0.8 |
8 8/0.8 |
8 8/0.8 |
8 8/0.8 |
8 8/0.8 |
8 8/0.8 |
7 7/0.7 |
Running Speed m/min |
20/30 |
||||||
Wire Rope Type |
6*19-3.6 |
6*37-4.8-180 |
6*37-7.4-180 |
6*37-11-155 |
6*37-13-170 |
6*37-15-200 |
6*37-15-200 |
I Beam Track Type |
16-22b |
16-28b |
16-28b |
20a-32c |
20a-32c |
25a-63c |
28a-63c |
|
Loop Track Minimum Radius m |
0.8 |
1.5 |
1.5-4 |
2-4 |
2-4 |
2.5-5 |
3.5-9 |
Voltage V |
380 |
380 |
380 |
380 |
380 |
380 |
380 |
Frequency HZ |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
Phase |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
CD1 MD1 electric wire rope hoist information need:
1. Capacity
2. Lifting height
3. Lifting speed and running speed requirement.
4. Power supply
5. Any other special requirement you need,like I beam type
Note
1. We only manufacture the high quality hoist
2. Different power supply available
3. OEM
4. Color variety
