portable crane scale 500kg
- 30000 Piece / Pieces per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | JNDO | Model Number: | OCS-SP |
Type: | Crane Scale | Power Supply: | DC9V/1000mA | Display Type: | LCD LED |
Rated Load: | 500kgs |
Product Description
portable crane scale 500kg
features of crane scale 500kg:
1.Multi-Weighing Units
Kg, lb, N are selectable, generally kg is the default unit.
2. Multi-function operation
Tare;Zero;Auto zero tracking;Total;Hold; Overload warning,operation through remote controller functions.
3. User-friendly design
Cast aluminium housing and aluminium front panel for maximum protection; Large red 5 digit LED display (digit height: 30mm); Safety factor up to 4 times capacity; Battery Operated with low battery indication; Automatic switch-off power-saving function.
Main technical data of crane scale 500kg:
Standard | OIML class III |
Display | 30mm (1.2’’) 5digits LCD/LED |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Stable Time | ≤10seconds |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Life | ≥50 hours |
Battery Type | Fully sealed Lead-Acid battery, 6V/5Ah |
Adapter | DC9V/1000mA |
Operating Humidity | ≤85% RH under 20°C |
Remote Controller Distance | Min. 15m |
Battery of Remote Controller | AAA battery, 1.5V×2 |
Operating Temp | - 10°C ~ + 40°C |
Specification of crane scale 500kg :
MODEL | Max. capacity( kg) | Min.weigh(kg) | Division(kg) | Total dispay counts(n) |
---|---|---|---|---|
OCS-SP-005 | 50 | 0.4 | 0.02 | 2500 |
OCS-SP-01 | 100 | 1 | 0.05 | 2000 |
OCS-SP-02 | 200 | 2 | 0.1 | 2000 |
OCS-SP-03 | 300 | 2 | 0.1 | 3000 |
OCS-SP-05 | 500 | 4 | 0.2 | 2500 |
OCS-SP-1 | 1000 | 10 | 0.5 | 2000 |
MODEL | A(mm) | C(mm) | H(mm) | N.W.(kg) |
---|---|---|---|---|
OCS-SP-005 | 33 | 24 | 320 | 4 |
OCS-SP-01 | 33 | 24 | 320 | 4 |
OCS-SP-02 | 33 | 24 | 320 | 4 |
OCS-SP-03 | 33 | 24 | 320 | 4 |
OCS-SP-05 | 41 | 25 | 345 | 4.2 |
OCS-SP-1 | 41 | 25 | 345 | 4.2 |
