Specifications
water/heat proof 5000kg digital hanging scale1.Capacity:2ton to 50 ton
2.Unit:kg,lb
3.CE
water/heat proof 5000kg digital hanging scale
OCS-SL Crane Scale for Weighing Portable size, RS232 port,USB port, bi-directional control fuction with printer moderate price.
Features of Crane Scale:
1.30MM(1.2'')LED display with readablity
2.High quality square die casting aluminum,sturdy and durable
3.With storing function for the present, it is convenient to record weight
4.Automatic dormancy/shutdown saving energy design
5.Weight accumulation and demanding function
6.Handheld remote control with operating easily and convenience
7.With adjusting acceleation factor of gravity, suitable for all over the world
8.Display adjsting of speed and shakeproof rank, with small error and calibration by hand
9.Independent battery box design, it is easy to replace battery
MAIN TACHNICAL DATA:
Standard |
According to OIML class III |
Display |
30mm (1.2’’) 5digits LCD/LED |
Zero Range |
4% F.S. |
Tare Range |
100% F.S. |
Stable Time |
≤10seconds |
Overload Indication |
100% F.S. + 9e |
Max. Safety Load |
125% F.S. |
Ultimate Load |
400% F.S. |
Battery Life |
≥50 hours |
Battery Type |
Fully sealed Lead-Acid battery, 6V/4.5Ah |
Adapter |
DC9V/1000mA |
Operating Humidity |
≤85% RH under 20°C |
Remote Controller Distance |
Min. 15m |
Battery of Remote Controller |
AAA battery, 1.5V×2 |
Parameters of Crane Scale:
MODEL |
Max. capacity(kg) |
Min. weigh(kg) |
Division(kg) |
Total dispay counts(n) |
OCS-SL-2 |
2000 |
20 |
1 |
2000 |
OCS-SL-3 |
3000 |
20 |
1 |
3000 |
OCS-SL-5 |
5000 |
40 |
2 |
2500 |
OCS-SL-10 |
10000 |
100 |
5 |
3000 |
OCS-SL-15 |
15000 |
200 |
5 |
3000 |
OCS-SL-20 |
20000 |
200 |
10 |
2000 |
Illustration of Crane Scale:
MODEL |
A(mm) |
B(mm) |
C(mm) |
D(mm) |
E(mm) |
H(mm) |
N.W.(kg) |
OCS-SL-2 |
95 |
260 |
33 |
195 |
135 |
430 |
10.5 |
OCS-SL-3 |
95 |
260 |
40 |
195 |
135 |
455 |
11.5 |
OCS-SL-5 |
120 |
325 |
50 |
240 |
165 |
535 |
17.5 |
OCS-SL-10 |
124 |
325 |
60 |
240 |
165 |
660 |
27.5 |
OCS-SL-15 |
225 |
345 |
70 |
240 |
165 |
855 |
49 |
OCS-SL-20 |
225 |
345 |
85 |
240 |
165 |
920 |
56 |
