Vacuum sintering furnace with dewaxing in vacuum
1. Application
The sintering is the key process in the production process of powder metallurgy,it can ensure good quality powder metallurgy.
At present,it is dewaxing and sintering furnace with many kinds of atmosphere.It is used to dewax ,sintering in vacuum or atmosphere processing.
2. Features
A. Intelligent temperature controller, automatic control with uniform temperature. It can complete the whole heating process automatically according to the setting program;
B. High degree automation, the process is completed by the computer automatically;
C. It enhance product physical and chemical properties, to ensure the quality of the product.
3. Main technical parameters
Model | LZL-38/30/60-1600-1-03 | LZL-60/45/90-1650-2-T-03 |
Specifications | 68L | 245L |
Temperature control | 1 zone | 3 zones |
Working area size (W.H.L) | 380×300×600mm | 600×450×900mm |
Limit vacuum | ≤1Pa | ≤1Pa |
Leakage rate Pa/h(empty furnace cold state,24hours calculation) | ≤80Pa | ≤80Pa |
Max heating rate | 10°C/min | 10°C/min |
Max power | 15KVA×3 | 110KVA×3 |
Max temperature | 1600°C | 1600°C |
Actual work temperature | ≤1550°C | ≤1550°C |
Furnace size(L.W.H) | 2000x1400x1850mm | 2500x2000x2400mm |
Mechanical pump model | 2H-30 | 2X—30 |
Roots pump model | JZJ-150 | Z—300 |
Wax recovery rate | ≥90% |
|
Cooling time | ≤8 hours |
|
Load | ≤40kg | ≤360kg |
Weight(kg) | 4000kg | 9000kg |
Floor area | 4500×6000 mm | 6000×8000 mm |
