4Hseries 4/3 Hand Lever Valves Pneumatic Hand Switch Valve

Name: 4Hseries 4/3 Hand Lever Valves Pneumatic Hand Switch Valve
Brand: raypoo
SKU: 141614604
Availability: InStock

4Hseries 4/3 Hand Lever Valves Pneumatic Hand Switch Valve thumbnail-1

4Hseries 4/3 Hand Lever Valves Pneumatic Hand Switch Valve photo-1

US$ 25 - 35 MOQ: 1 Piece

Key Specifications

Get Latest Price

Type:

Valves

Place of Origin:

Guangdong, China

Model Number:

Contact Supplier Request Quote Chat Now

Shenzhen Raypoo Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Valves

Place of Origin Guangdong, China

Model Number 4H

Brand Name raypoo

Product Description

4H series 4/3 hand lever valves pneumatic hand switch valve

1.4/3-way hand-lever valve has three central functions for your choice;

2.The direction-change turns lightly with good hand feeling and exact orientation;

3.Large effective circulating area leads to little pressure loss;

4.Panel and body installation are optional. The panel installation can be attached with installing nut

Ordering Code

Example	4H	2	30	C	06	S
Meaings	Model	Code	Valve type	Position	Port size	Installation
Explain	4H: Hand lever valve	2:2series 3:3 series 4:4 series	10:4 port 2 position 30;4 port 3 position	C: close center E: exhaust center P: pressure center	06:PT1/8 08:PT1/4” 10:3/8” 10:1/2” 15:3/4”	Blank: body Installation S: panel installation

Specification

Model	4HV200-06	4HV200-08	4HV300-08	4HV300-10	4HV400-15	4HV400-20
Fluid	Air (to be filtered by 40um filter element)
Operating	Manual control direct acting type
Port size	1/8”	1/4”	1/4”	3/8”	1/2”	3/4”
Orifice size	14.0mm2	16.0mm	30.0mm2	33.0mm2	88.0mm2	95.0mm2
Valve type	4 port 2 position 4 port 3 position
Lubrication	Not required
Operating pressure	0~0.8Mpa (0~116 Psi)
Proof pressure	1.5 Mpa (215 Psi)
Temperature	-20~70
Material of body	Aluminum alloy

Packaging & Shipping

How are orders packed and shipped?

Depends on customers' orders. All goods are packed with a plastic bag with an outer carton and a wooden pallet( fumigation).

Can be customized according to customer requirements

Our Services

We provide hydraulic, lubrication, pneumatic technology consulting, system design, and the parts.

Could Raypoo offer OEM service?

Yes. Raypo is able to offer OEM with customers' brand name and trademark onto the product.

Do Raypoo products come with a warranty?

Yes.Raypoo offer 1-year guarantee without abusive usage on all purchases which begins with the bill of lading.

Company Information

Shenzhen raypoo is a manufacturer of hydraulic products and engineered solutions serving the fluid power market.

The Company offers an engineering and manufacturing team capable of providing advanced technology in the design and production of unique fluid power components and electronic controls.

The Company's involvement focuses its expertise on markets in which customers demand top quality, prompt delivery, high performance and responsive aftermarket support.

The Company's products include hydraulic pumps, hydraulic motors, hydraulic valve ,valves controls manifolds, ,hydraulic cylinders, Industries that use these products include primary metals, machine tool, automobile, petroleum, construction equipment, chemical, plastic, glass, lumber, rubber and food.

The Company strives to serve those markets requiring high technology and expertise where reliability, top performance and longer service life are needed.

The products are sold as individual components or integrated into high performanceapplications.
