FSJ Stainless Steel Cocoa Bean Winnower
Application
Vegetable winnowing separator has a wide application. It can separate almost all kinds of products which has different specific gravity, especially for fruits and vegetables, for separating stems and leaves of vegetables; separating and grading vegetables, fruits and other dried products, specially for green bean, soybean,cabbage and spinach
Features
This machine is featured by simple structure, stable operation, low noise, low energy consumption, excellent separating and grading performance.
Working principle
This machine is made of high quality stainless steel, conveyed by food grade flat belt, separated by low-noise centrifugal ventilator.
Materials go from hopper, conveyed by flat belt, into separator inlet; simultaneously, wind blasts from bottom to up, winnowing separating materials: the sundries blown out from debris outlet, the final products blown out from material outlet via ventilating duct. Wind power can be adjusted according to the materials.
Main technical parameters
Capacity: 1.5kg/h ( based on green bean)
Power: 4.75Kw
speed: 1.5~7.5m /min (manual adjustment)
blast volume:900m3/h (manual adjustment)
Dimension: 4200mmX1445mmX3000mm
Weight of machine: 520kg
| model | dimension(mm) | power(kw) | speed(m/min) | air volume | capacity(t/h) |
| FSJ-A | 4200*1445*3000 | 4.75 | 1.5-7.5 | adjustable | 1.5 |
The machine can be customized according to our customers' requirements, above specafication is our common one.
Zhejiang Sanshon Machinery Manufacturing Co., Ltd was founded in 1993, located in the most convenient transportation and prosperous economy of Yangtze River delta Shangyu city, Zhejiang. Zhejiang Sanshon Machinery Manufacturing Co., Ltd adjacent to the beauty of the CaoE river, and in less than 5 KM there are three expressways, they are Hangzhou-Ningbo (G92), Changshu-Taizhou (G15w), and 104 national road line , the HangYong high speed railway. Moreover it is less than 100 KM to Hangzhou and Ningbo airport.
It is specialized in manufacturing food processing machinery, which includes fruit & vegetable hot air drying(AD), quick freezing (IQF), vacuum freeze dryer(FD). The company passed ISO9001:2000 quality standard under the efforts of all employees. There are three equipments has been assessed as National New Product. And in 2007, Sanshon was recognized for New and High Technical enterprise in Zhejiang Province.
The company not only in r&d and manufacturing ,but also enjoy the right of import and export. And the machinery from Sanshon has been exported to more than 10 countries, including Vietnam, Thailand, Uzbekistan, Azerbaijan, Iran, Mexico, Venezuela, Peru, Australia, Cyprus, Libya, etc.
Based on more than 20 years’ experience in food process machinery manufacturing, later it established Shaoxing Sanshon Steel Co., Ltd () and Shundi foods Co., Ltd()in Zhejiang and Shanghai. Sanshon now is capable of providing integrated services, including product consultation, design, workshop establishment, equipment manufacturing and installation, training of machine operation in the field of vacuum freeze drying machine (FD), hot air drying (AD) as well as quick frozen (IQF) machines.
Sanshon is well prepared to be a pioneer in the field of dehydration, quick frozen, vacuum freeze drying to contribute to food processing industry!
Term,Conditions
Ordering Information
Payment:
we usually accept T/T,L/C, please send email to negotiate payment term if you can not accept T/T or L/C.
Packing:
iron framework with external plywood and seaworthy package
Please send email for the extra cost of different packing
Delivery Time:
different products will spend different production period: from 30-120 days after 50% advanced payment.
For urgent order, Could be faster, please send email to negotiate
How to make an order?
1,Client make 50% deposit or open LC after receiving our PI
2,Client approve our equipment,
arrange shipment
1,Client effect balance payment before shipment
2.supplier send original documents or telex release the goods
3,quality warranty for 1 year after shipment
