Fruit and Vegetable Industrial Food Drying Machine
Application
Fruit and vegetable drying machine is designed to meet the requirements of export-aimed dehydrated vegetables and fruits. It has a wide application, is suitalbe for all kinds of products.
Main technical parameters
STJ-I box dryer
overall dimensions: 3600*2000*1585mm
blast volume: 9700m3/h
blast pressure(blower fan): 774pa
power (blower fan):5.5Kw
quantity(blower fan): 1set
steam consumption: 150~200kg/h(≥0.4mpa)
drying area: 4m2
drying capacity: 50 KgH2O/h
temperature: normal temp.~110°c (controlled both automatically and manually)
SBJ belt dryer
Model | Overall dimension (mm) | Power (kw) | Capacity (t/h) | Steam consumption (t/h, peak value,≥0.4mpa) | Valid width of belt (m) | Valid length of belt (m) |
SBJ-2S-24 | 13700*3140*2990 | 53.22 | 1 (calculated as potato dice) | 1.8 | 2.0 | 12.0 |
SBJ-2M-60 | 14900*2940*3900 | 21.0 | 1 (calculated as potato dice) | 0.8 | 2.0 | 10.0 |
SBJ-2-32 | 18400*5500*3500 | 59.22 | 1.5 (calculated as wheat) | 4.0 | 2.0 | 16.0 |
SBJ-2-16 | 11900*5500*3500 | 34.50 | 0.5 (calculated as wheat) | 1.8 | 2.0 | 8.0 |
SSJ tunnel dryer
Model | Dimension (mm) | Power (kw) | Air input (m3/h) | Air output (m3/h) | Capacity (kg/h) | Steam consumption (kg/h, peak vale≥0.4MPa ) | Tray’s size (mm) | Tray’s qty (pcs) | Trolley’s size (mm) | Trolley’s qty (pcs) |
SSJ-8-250 (insulation plate) | 11950×1900×2550 | 8.5 | 40000 | 18000 | 2500 | 500 | 934*775*18 | 352 | 1628*1000*1980 | 8 |
SSJ-7-25 (civil engineering wall) | 11300×2580×3120 | 10.5 | 54000 | 22000 | 2500 | 500 | 934*590*18 | 462 | 1980*1000*1980 | 7 |
SSJ-11-400 (civil engineering wall) | 15300×2580×3120 | 17.0 | 60000 | 24000 | 4000 | 700 | 934*590*18 | 726 | 1980*1000*1980 | 11 |
Zhejiang Sanshon Machinery Manufacturing Co., Ltd was founded in 1993, located in the most convenient transportation and prosperous economy of Yangtze River delta Shangyu city, Zhejiang. Zhejiang Sanshon Machinery Manufacturing Co., Ltd adjacent to the beauty of the CaoE river, and in less than 5 KM there are three expressways, they are Hangzhou-Ningbo (G92), Changshu-Taizhou (G15w), and 104 national road line , the HangYong high speed railway. Moreover it is less than 100 KM to Hangzhou and Ningbo airport.
It is specialized in manufacturing food processing machinery, which includes fruit & vegetable hot air drying(AD), quick freezing (IQF), vacuum freeze dryer(FD). The company passed ISO9001:2000 quality standard under the efforts of all employees. There are three equipments has been assessed as National New Product. And in 2007, Sanshon was recognized for New and High Technical enterprise in Zhejiang Province.
The company not only in r&d and manufacturing ,but also enjoy the right of import and export. And the machinery from Sanshon has been exported to more than 10 countries, including Vietnam, Thailand, Uzbekistan, Azerbaijan, Iran, Mexico, Venezuela, Peru, Australia, Cyprus, Libya, etc.
Based on more than 20 years’ experience in food process machinery manufacturing, later it established Shaoxing Sanshon Steel Co., Ltd () and Shundi foods Co., Ltd()in Zhejiang and Shanghai. Sanshon now is capable of providing integrated services, including product consultation, design, workshop establishment, equipment manufacturing and installation, training of machine operation in the field of vacuum freeze drying machine (FD), hot air drying (AD) as well as quick frozen (IQF) machines.
Sanshon is well prepared to be a pioneer in the field of dehydration, quick frozen, vacuum freeze drying to contribute to food processing industry!
Term,Conditions
Ordering Information
Payment:
we usually accept T/T,L/C, please send email to negotiate payment term if you can not accept T/T or L/C.
Packing:
iron framework with external plywood and seaworthy package
Please send email for the extra cost of different packing
Delivery Time:
different products will spend different production period: from 30-120 days after 50% advanced payment.
For urgent order, Could be faster, please send email to negotiate
How to make an order?
1,Client make 50% deposit or open LC after receiving our PI
2,Client approve our equipment,
arrange shipment
1,Client effect balance payment before shipment
2.supplier send original documents or telex release the goods
3,quality warranty for 1 year after shipment
