API Oil Drill Bits for Gas Exploring

API Oil Drill Bits for Gas Exploring thumbnail-1
API Oil Drill Bits for Gas Exploring photo-1
US$ 10 - 1,000 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
ZM
Model Number:
made-to-order
Contact Supplier Request Quote Chat Now
Henan Zhongmei Drill Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or any China main ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name ZM
Model Number made-to-order
Type Other, Center Drill Bit, Drill Bit
Material Other, Diamond, High Manganese Steel
Use Other, Well Drilling, Coal Mining

Specifications

1.oil drill bits
2.do oil drill bits OEM
3.oil drill bits high qulaity
4.oil drill bits with ISO9001 and IADC standard

diamond Oil drill bits for gas exploring

PDC bit/PDC oil bit/oil drill bit

The main structure features:

Tungsten carbide matrix PDC possesses high wear resistance and impact resistance.

Parabolic crown profile and maxises junk slot area can clean bit better, and prolong the bits working life.

PDC cutters are sintered with selected diamond powder and tungsten carbide under high temperature and ultra-high pressure, they are widely used in oil/gas drill bits, geological drilling and mining bits, and also can be used in rock cutting tool.

Feature:

1.high wear resistance, impact resistance and thermal stability
2.stable quality and competitive price
3.timely delivery

   Applying hydraulics balance design, 5 renewal nozzles and reasonable nozzles locating angle can gain ideal fluid field in well bottom,fully clean and cool cutter, and prolong the cutter working life.

   Non-symmetry blade arrangement enhances drilling well balance.

   Optimization for cutter shape, slant angle, cutter numbers prolong the cutter working life in combination with high quality PDC cutter, and improve ROP and drilling efficiency.

   It can be used for on rotary or down hole motor

   Hign HIS is recommende

TYPE

SIZE

API PIN SIZE

WEIGNT(KGS)

INCH

MM

8 1/2M1234AL

8 1/2

215.9

4 1/2REG

70

8 1/2M3235AL

8 1/2

215.9

4 1/2REG

70

8 1/2M3235BLF

8 1/2

215.9

4 1/2REG

70

8 1/2M2235L

8 1/2

215.9

4 1/2REG

70

8 1/2M3236AL

8 1/2

215.9

4 1/2REG

70

8 3/4M3235AL

8 3/4

222.3

4 1/2REG

72

9 1/2M3235L

9 1/2

241.3

6 5/8REG

85

9 1/2M3236L

9 1/2

241.3

6 5/8REG

85

12 1/4M3235

12 1/4

311.1

6 5/8REG

105





















Notes:Non-standard items also can be made as your detailed demand.

API oil drill bits for gas exploring
