Six Blades PDC Non-coring Bit

Specifications

Good Quality & Favourable Price
========================
Six Blades PDC Non-coring Bit
Use:Coal mining,water conservancy,etc.

Introduction

PDC bit uses PDC as main cutting components, with the excellent wear-ability and impact toughness of the PDC. It has a useful life, high-efficiency, and good performance cost ratio.

Henan zhongmei can supply all kinds of PDC Coring and non-coring bits, PDC sintering matrix bits and PDC anchoring bits. PDC bit can be widely used in the fields of geological exploration, coal mining, water conservancy and hydropower, construction of road and railway.

We also can design PDC bits according to customer requirements, such as different geological condition, special strata and so on.



Theory

PDC(polycrystalline diamond compact) drill bit is a new product after the hot-pressed and electroplated drill bit recent years.With special hith-frequency weldin techniques.PDC of high wear resistant si welded to the body as cutting edges.PDC bit is mainly used for geological prospecting,coal exploration,water conservancy and power engineering,etc.



Features

1.       It has a super long life. The grinding/consumption ratio of PDC is 20-40 times that of tungsten carbide bit and 10 times that of diamond bit.

2.       It had high drilling speed.

3.       It can be operated with low pressure and low speed.

4.       It has a good gage protection.

5.       It can be used widely, more suitable for drilling in the stratum with formation<7

6.       It has a low cost



Applicaton

PDC bit is mainly used for drilling soft and medium formation, it work under low drilling pressure,midium-low speed,big drainage.



Specification

PDC Non-coring Bit is a kind of full face bit, it is mainly used for coal mining, water canservancy and hydropower, road construction, railway, bridge and building.



Specification diameter(mm)	Size		Cutting Wings		Water Hole		Threading	Rock Formation
	Dia(mm)	Height(mm)	Pillar Quantity	Blade Quantity	Quantity	Quantity
56	56	115	2	3	4	6--8	Square Taper Lock	F<7 medium hard (Dagstone; sandstone; Limestone)
60	60	115	2	3	4	6--8
65	65	115	2	3	4--5	6--8
75	75	125	2	3--4	4--6	6--10
78	78	128	2	3--4	4--6	6--10
85	85	128	2	3--4	4--6	8--12
94	94	128	2	3--4	4--8	8--12
113	113	135	3	3--4	6--8	8--12
133	133	135	3	3--4	6--8	8--12





We are also can design and manufacture of various non-standard drill tools.



If you have any questions, please feel free to contact us.
