Help CenterHydraulic 24V Wet - Pin Type GP80-4-XT Proportional Solenoid
Related Products
-
Screw Connected Type & Proportional Electric ActuatorUS$ 35 - 50MOQ: 200 Units -
Screw Threaded Type & Proportional Soleniod SensorNegotiableMOQ: 60 Units
-
Screw Threaded Type & Proportional ElectromagnetNegotiableMOQ: 60 Units
-
SV37-1 Screw Thread Valve With Proportional Cartridge SolenoidNegotiableMOQ: 50 Units
-
SV22-40YC Screw Thread Valve With Proportional Cartridge CoilsNegotiableMOQ: 50 Units
Specifications
Proportional coils within the rated stroke current range, this series solenoid output magnetic force is proportional signalModel: Proportional Solenoid GP80-4-XT
Within the rated stroke and current range, this solenoid output magnetic force is exactly proportional to the input single, and it can be matched with the Proportion Control Amplifiers to achieve the precise control of the valve plungers. This solenoid is usually used in the proportional spillover valves, proportional flow control valves, proportional throttle valves, proportional compound valves etc, with the higher repetition precision and the good linearity plus.
Pecifications
Model No. |
Rated Current A |
Rated Magnetic Force N |
Rated Stroke mm |
Full Strokemm |
Relative Duty Rating % |
Resistance 20°C V |
Hysteresis Magnetic Force % |
Hysteresis Magnetic Current % |
Repetition Precision% |
Oil Pressure Duration MPa |
GP80-4 - XT |
0.6 |
90 |
9 |
10 |
100 |
41 |
≤ 3.8 |
≤ 4 |
≤ 1 |
21 |
Applications and Features
Stable State Stroke- Mechanical Property Curve
Advantage:
1. Low MOQ: It can meet your promotional business very well.
2.OEM Accepted: we can produce any your design.
3.Good service: We treat clients as friend.
4.Good quality: we have strict quality conrol system. Good reputation in the market.
5. Fast& cheap delivery: we have big discount from forwarder(long Contract)
Order Guide:
Genaral Order Information
We take great pride in our work and in the wide variety of products that we offer. We are experienced in servicing the US market, European Market and Africa Market. Pls be aware that on our understanding of the demands and nature of promotional and marketing deadlines,That's why we always ensure that every order is delivered on time.
