Specifications
PP/PPR/PE pipe prodction linehigh quality water supply and gas supply pipes with excellent hardness and flexbility.
PP/PPR/PE pipe prodction line
Detailed Product Description
Brief Introduction:
This production line has production capacity of churning out φ16mm-φ160mm PPR pipe continuously with assembling the special high-speed single screw extruder,which is distinguishingly designes with co-extrusion die head,the production stress,anti-corrosion,antibiosis,shock resistance,aging resistant,no leakage,light weight,econominc investment,convenient application and so on.This facility can also be used to produce the HDPE silicone core pipe,PB pipe,PE pipe,PEX pipe,PP pipe,ect.
Theecnomic and technical norms of the finiahed products are all reached the interbational standards after been detected by Nation chemical construction test center,which are the first choices to replace the traditional galvanized pipe and applicable to so many fields,such as conveying the hot and cold water,central-heating.and floor heating.
Main Technical Paramerets:
| ItemModle | SJ-30 | SJ-45 | SJ-65 | SJ-90 | SJ-90 | SJ-90 |
| Length Diameter Ratio(L/D) | 25-33 | 25-33 | 25-33 | 25-33 | 25-33 | 25-33 |
| Main Motor Power (kw) | 2.2-7.5 | 7.5-22 | 18.5-55 | 55-185 | 90-280 | 110-300 |
| Heating Power (kw) | 5-8 | 6-12 | 12-18 | 16-40 | 20-60 | 30-80 |
| Cooling Mode | Air Cooling and Water Cooling | |||||
| Max.Extruding Capacity (kg/h) | 18 | 60 | 180 | 450 | 650 | 950 |
Equipment component
Equipment |
Count |
Powder loader |
One set |
| single screw extruder | One set |
Mould |
It depends |
Water spraying cooling tank |
One set |
Haul-off |
One set |
Cutter |
One set |
Stacker |
One set |
Auto electric control cabinet |
One set |
crusher |
One set |
According to the products and customer's requirements finalized
