Technical characteristics:
- 1. Color high-resolution CCD image acquisition system
l Use the color CCD image acquisition system to acquire the comprehensive information of red, green and blue color. The color sorter has the sensory ability of human eye, making better selection of materials, and satisfying the requirements better.
l The maximum resolution is up to 0.15mm, can accurately identify small defects and spots on industrial raw materials, and the high-precision special lens ensures clear images.
- 2. Configuration of flexible and variable light source.
l Led lighting system with radiato, long service life, low energy consumption, good performance.
l Different industrial raw materials require different spectra, we customize the light source according to the need of customer.
- 3. Dedicated image processing algorithm.
l According to the characteristics of material, use the shape and color combination algorithm.
l For materials with complex colors, the machine sorts materials more directly and accurately by using HSV-changed color space sorting method.
- 4. Unique trough configuration
l The special anodizing technology can ensure production volume as well as conformity with the international standard.
l The machine can be equipped with cascade plate and narrow chute channel to meet the color sorting for various materials.
- 5. High-quality solenoid valve
l Use high quality ,high frequency ,long service life ejecter, super low air consumption guaranteed the biggest capacity, excellent rejection output
l For the different sizes and characteristics of material particle, use the solenoid valve of different sizes.
- 6. Excellent rejection rate(carryover rate)
l Advanced image acquisition system+intelligent image processing algorithms + high quality nozzle system = excellent elimination rate
- 7. Simple operation, easy to learn and use
l Simple optical system design, precise automatic correction system, combined with the well-designed human-machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use.
Specification:
Model |
6SXG-126 |
6SXG-189 |
6SXG-252 |
6SXG-315 |
6SXG-378 |
6SXG-84 |
6SXG-126 |
6SXG-168 |
6SXG-210 |
6SXG-252 |
|
Product output(t/h) |
0.2-0.3 |
0.5-5.0 |
1.0-7.0 |
1.5-9.0 |
2.0-11.0 |
Sorting Accuarcy % |
>=99 |
>=99 |
>=99 |
>=99 |
>=99 |
Carryover Rate (bad:good) |
>=7:1 |
>=7:1 |
>=7:1 |
>=7:1 |
>=7:1 |
Weight(kgs) |
670 |
820 |
970 |
1120 |
1200 |
Resolution(mm2) |
0.04 |
0.04 |
0.04 |
0.04 |
0.04 |
Power(KW) |
1.4 |
1.8 |
2.2 |
2.6 |
3.0 |
Dimension (L*W*Hmm) |
1337*1636*2070 |
1651*1636*2070 |
1965*1636*2070 |
2279*1636*2070 |
2593*1636*2070 |
Power supply(V/HZ) |
220/50(110/60) |
220/50(110/60) |
220/50(110/60) |
220/50(110/60) |
220/50(110/60) |
- 1. The above data is based on 5% contamination plastic material, and real output depends on the plastic material and its contamination.
- 2. If products update, no further notice, please refer to the real machine.
SAIOU did export business since 2006,so we have the certifications which suit for shipping our products: plastic crushing washing drying machine, plastic pelletizing machine, plastic pipes production line ,shredders ,all include our machines.And we also have quality certification.
Our machines export to USA, RUSSIA,BULGARIA,CHILE,MALAYSIA,CAMBODIA,VIETNAM,KOREA,MEXICO,INDIA,BANGLADESH etc, too much places.
wooden packing cover with foil.
Service commitment:
one year free repair and maintenance for complete machine, 24h door-to-door fast response,7*24h service,Estabilsh user file for follow-up service.
skype: saiouzjg
whatsapp: +86-13962247879
wechart: +86-13962247879
