Vertical heating temperature oven

Specifications

protection with temperature control, with the timing of digital display microcomputer controllers, with accurate and reliable.



Vertical heating temperature oven DGG series







For industrial, laboratory and research institutes such as dry, baking melted wax, sterilization



Features



1. the protection with temperature control, with the timing of digital display microcomputer controllers, with accurate and reliable.
2. box uses the mirror stainless steel or glass plate material argon-arc welding, box outside the use of high-quality steel materials, elegant, innovative.
3. forced convection vertical, vertical, the German original fan, the Studio even temperature.
4. the independent limited temperature alarm system, exceeding the limit temperature automatically interrupted, ensure experimental safety is not an accident. (Optional)



Technical parameter



Model	Vertical heating temperature oven DGG series
	9030A 9036A	9070A 9076A	9140A 9146A	9240A 9246A
The power supply voltage	220V50Hz
Range of temperature control	DGG-9000series:RT+10°C~200°C DGG-9006series:RT+10°C~300°C
Temperature resolution	0.1°C
Constant volatility	±1°C
Input power	600W/970W	1150W/1600W	1600W/2100W	2100W/2500W
working temperature	5°C~40°C
Inner dimensions(mm)	300×300×350	400×400×450	450×550×550	500×600×750
Dimensions(mm)	445×470×705	550×600×800	640×700×905	690×780×1100
Loading bays (standard)	2block
Scheduled	1~9999 minutes







model	Vertical heating temperature oven DGG series
	9420A 9426A	9620A 9626A
The power supply voltage	380V50Hz
Range of temperature control	DGG-9000 series:RT+10°C~200°C DGG-9006 series RT+10°C~300°C
Temperature resolution	0.1°C
Constant volatility	±1°C
Input power	3200W/3300W	4100W/4200W
Operating temperature	5°C~40°C
Inner dimensions(mm)	600×550×1300	800×600×1300
Dimensions(mm)	780×760×1800	980×800×1800
Loading bays (standard)	3block	4block
scheduled	1~9999 minutes







Note: performance measurement in the unloaded condition: ambient temperature of 20 ° c and relative humidity of 50% RH











Note: performance measurement in the unloaded condition: ambient temperature of 20 ° c and relative humidity of 50% RH
