HF120W DTH Drilling Machine Working With Air Compressor, High Efficient

HF120W DTH Drilling Machine Working With Air Compressor, High Efficient photo-1
US$ 8,500 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Brand Name Hanfa
Model Number HF120W
Usage Water Well
Certification ISO
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

DTH drilling machine
1.120m depth
2 High drilling efficiency,Low cost
3.:ISO drilling rig
4. trailer type, easy movin

Best Quality HF120W DTH drilling machine



 1. Application of HF series water well/core drilling rig
Since our establishment in 2004, we have been devoting ourselves to researching and developing easy-operation, highly-efficient and large-capacity drilling rigs. Designed for multiple functions,our HF series water well/core drilling rigs are designed for geological exploration, water well drilling, soil sampling, core sampling(normal coring and wireline coring), pile drilling, etc.



 2. technical parameters about this DTH drilling machine



I. Features and Advantages



The HF120W is a Trailer mounted water well drilling rig, compact fully hydraulic, for down-the-hole



2. The technical parameters of DTH drilling machine





Description

HF120W

Geology drilled

All kinds

Drill depth

0-120 m

Drilling Diameter

90 -140mm

Drill system and operation

Hydraulic

DRILL PIPE



Drill pipe length

2.00 meter

Drill pipe diameter

60/76 mm

MUD PUMP



Flow capacity

200 liter/min

Max. working pressure

1.8MPA

HYDRAULIC SYSTEM



Hydraulic tank capacity

140 liter

DIMENSIONS



Overall length

3200 mm

Overall width

1400 mm

Overall height

1500 mm

Diesel engine



Power

16.2KW

HF120W DTH drilling machine working with air compressor, high efficientHF120W DTH drilling machine working with air compressor, high efficientHF120W DTH drilling machine working with air compressor, high efficientHF120W DTH drilling machine working with air compressor, high efficientHF120W DTH drilling machine working with air compressor, high efficient




Improved model of DTH drilling machine HF410T



HF120W DTH drilling machine working with air compressor, high efficientHF120W DTH drilling machine working with air compressor, high efficientHF120W DTH drilling machine working with air compressor, high efficient
