High drilling efficiency! High power! S600 tractor mounted drilling rig
1.S600 drilling rig technical data:
Max.diameter of turntable |
650 |
Drilling Depth(mm) |
600 |
Turntable Speed(r/min) |
22,59,86,126 |
Torque(KN.m) |
13.7,5.1,3.5,2.3 |
Effective Heigh of Rig(m) |
14 |
Load of Rig(kN) |
294 |
|
Averall dimensions (m)
(L×W×H) |
Railing State 10×2.8×4.1 |
|
Working State 5.65×4.15×16.7 | |
Weight (t) |
10.5 |
2. Description of S600 trailer-mounted drilling rig :
1.Professional for water well drilling.It was awarded the National Scientific Research Achievement Prize by Chinese government and highly recommoned by its users for good quality and operation.
2.It’s well suited for exploring water sources,drilling industrial,agricultural,civil wells,and constructing piles and
ventilation holes for underground cannels.The drill can work in various geological conditions,can wok in various
geological conditons,applying the rotary drill and direct/reverse circultaion.
3..Convenient to use.Possesses an integral drill tower and a partly hydraulic operated.
4.It is characterized by trailer moving ,mechanical transmission,partially hydraulic lift/lowering,easy delivery and
high degree of mechanization.It opetates very efficiently drilling deep,large liameter holes with high torque.
