most popular on the market!! HF100YA2 DTH blasthole drilling machine
USD $12,000 - $15,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Qingdao
You May Like
-
2013 Most popular , HF100YA2 small DTH blasthole drilling rig
-
smallest, HF100YA2 small DTH drilling rig
-
Multi-function wheel type drilling rig for selling! HF150T wheel type multi-function rotary water well drilling rig
-
Strong ability and multi-function drilling rig for selling! HF150T wheel type multi-function water well drilling rig
-
Wheel type high efficiency drilling rig for selling!HF150T multi-function water well drilling rig
-
Multi-function used rock drilling rig! HF150T wheel type water well drilling rig
Product Details
| Condition | New | Type | Other, Down the hole drilling rig | |
| Power Type | Diesel | Brand Name | Hanfa | |
| Model Number | HF100Y | Usage | Water Well | |
| Power(W) | 18.6KW | Dimension(L*W*H) | 4100*2030*2020 | |
| Weight | 2600KG | Certification | ISO | |
| Warranty | 12Months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
HF100Y DTH blasthole drilling machine1,small crawler,hydraulic type
2,easy to move and operate
3,CE
HF100Y DTH blasthole drilling machine
I. Application
HF100Y DTH drilling rig can be used for urban construction, railway, highway, river, hydroelectric project and other projects in the rock drilling anchor holes, blast hole, bolt holes, blow holes, grouting hole, etc. It could drill hard rock with rock hardness f = 8-16.
II. Features
1. Caterpillar type, easy to transport.
2. High mechanical efficiency, low cost and stable performance.
3. Easy to operate, needing little experience to operate.
4. Economical and reasonable price.
| Main Machine Technical Parameter | |
| Model | HF100Y |
| Borehole diameter | 90-130mm |
| Rock type | Rock, hard rock, f=8-16 |
| Bore depth | 30m |
| Air pressure | 0.7-1.0Mpa |
| Air consumption | 7-15m³ /min |
| Flush-out frequency | 840 r/min |
| Gradeability | 30° |
| Travel speed | 2km/h |
| Pitch angle of carriage | up and down 10° |
| Tilt angle of carriage | left 35° right 10° |
| Length compensation of carriage | 900m |
| Engine | |
| Oil | diesel |
| Power | 18.6KW (25HP) |
| Weight | 2.6T |
