Perfect Quality DTH Hammers Bit
The DTH is the abbreviation of Down The Hole and sometimes it is also called RAB in some markets, then the RAB is short for Rotary Air Blasting.
A rotation drill rig, air compressor and the DTH drill string are the essential unit for DTH drilling while the "DTH drill string" is always made up of DTH drill rods, DTH hammer and DTH bits. As one of key component, the DTH hammer acts as a role of converting the air pressure to the impact energy, simultaneously transferring impact energy and rotation force to DTH bits.
As specialist manufacturer and provider of DTH drilling tools, hereby we recommend our newest generation DTH hammer which is improved by absorbing art technology, selecting superior alloy steel and robust design. It is proved by more than thousands times of test that our newest DTH hammer has longer life , lower air consumption and 15% higher penetration speed compared the conventional DTH hammer in the market. In addition, it can work at the air pressure from 6 Bar to 35 Bar(0.6~ 3.5Mpa). At last, we developed various type of DTH hammer which can be compatible with DHD, COP, QL, MISSION and SD shank of DTH bits and performs very well. Therefore, the newest generation DTH Hammer is very popular among our customers and has a good market share as soon as it launched in the market.
GSE DHD Hammer
| GSE DHD hammer size | GSE DHD Hammer working pressure | The impact frequency when it is working on 18Bar |
| GSE DHD3.5 | 6 bar ~ 35 Bar | 32Hz |
| GSE DHD340 | 6 bar ~ 35 Bar | 31Hz |
| GSE DHD350 | 6 bar ~ 35 Bar | 30Hz |
| GSE DHD360 | 6 bar ~ 35 Bar | 28Hz |
| GSE DHD380 | 6 bar ~ 35 Bar | 23Hz |
GSE QL Hammer
| GSE QL hammer size | GSE QL hammer working pressure | The impact frequency when it is working on 18Bar |
| GSE QL40 | 6 bar ~ 35 Bar | 31Hz |
| GSE QL50 | 6 bar ~ 35 Bar | 30Hz |
| GSE QL60 | 6 bar ~ 35 Bar | 28Hz |
| GSE QL80 | 6 bar ~ 35 Bar | 23Hz |
GSE MISSION Hammer
| GSE MISSION hammer size | GSE MISSION hammer working pressure | The impact frequency when it is working on 18Bar |
| GSE MISSION 30 | 6 bar ~ 35 Bar | 33Hz |
| GSE MISSION 40 | 6 bar ~ 35 Bar | 33Hz |
| GSE MISSION 50 | 6 bar ~ 35 Bar | 33Hz |
| GSE MISSION 60 | 6 bar ~ 35 Bar | 30Hz |
| GSE MISSION 80 | 6 bar ~ 35 Bar | 25Hz |
GSE SD Hammer
| GSE SD hammer size | GSE SD hammer working pressure | The impact frequency when it is working on 18Bar |
| GSE SD4 | 6 bar ~ 35 Bar | 31Hz |
| GSE SD5 | 6 bar ~ 35 Bar | 30Hz |
| GSE SD6 | 6 bar ~ 35 Bar | 28Hz |
| GSE SD8 | 6 bar ~ 35 Bar | 23Hz |
