Bit Manufacturers Button Rock Drill Bits DTH Hammer Bits
US$ 900 - 1,900
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HF
Model Number:
Hammer Bits
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Henan, China
Brand Name
HF
Model Number
Hammer Bits
Type
Other, Hammer Bits, High Quality DTH Hammer
Machine Type
Drilling Tool
Certification
AISI
Material
High Manganese Steel
Processing Type
Forging
Use
Well Drilling
Bit Manufacturers Button Rock Drill Bits DTH Hammer Bits
Our DTH hammer and bits are compatible with CIR, DHD, QL,SD,Mission, etc. series of Atlas and Sandvik etc. They are with high efficiency, low failure rate and long service life. Even for all kinds of high hardness, high abrasive rocks and other harsh conditions, our drilling tools can also realize efficient and economical drilling.
|
----Type and Technical Specification of High Pressure DTH Hammers | ||||||||||||
|
Item |
GL330 |
GL335 |
GL340A |
GL345 |
GL350 |
GL355 |
GL360 |
GL380 |
GL3120 |
|||
|
Drilling Dia. (mm) |
82-85 |
90-93 |
105-130 |
105-130 |
130-152 |
130-152 |
152-305 |
203-350 |
302-508 |
|||
|
Hammer Length(mm) |
867 |
908 |
1052 |
1034 |
1387 |
1220 |
1450 |
1551 |
1934 |
|||
|
Outside Dia. (mm) |
71 |
81 |
92 |
98 |
114 |
124 |
136 |
181 |
275 |
|||
|
Weight(kg) |
19 |
21.8 |
38 |
39 |
69 |
74 |
126 |
277 |
642 |
|||
|
Working Pressure(Mpa) |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
|||
|
Air Consumption |
3-12 |
4.3-14.2 |
3.5-18 |
3.5-15 |
5.7-18 |
6.5-18 |
8.5-25 |
12-31 |
14-45 |
|||
|
(M3/Min.) | ||||||||||||
|
Torque(N.M) |
150 |
205 |
304 |
335 |
590 |
700 |
822 |
1560 |
2410 |
|||
|
Impact Frequency (Times/Min.) |
≥800 |
950-1500 |
≥800 |
≥800 |
810-1470 |
810-1500 |
820-1475 |
860-1510 |
980-1446 |
|||
|
Connection 1 |
48.8×4.2 |
API 2-3/8 |
API 2-3/8 |
API 2-3/8 |
API 3-1/2 |
API 2-3/8 |
API 3-1/2 |
API 4-1/2 |
API 6-5/8 |
|||
|
Connection 2 |
47-6 |
53-8 |
64-8 |
64-8 |
84-8 |
84-8 |
99.5-8 |
128-10 |
184-8 |
|||
|
High Efficient High Pressure Hammer | ||||||||||||
|
Item |
GL345A |
GL355K |
GL360K |
GL380K |
||||||||
|
Drilling Dia. (mm) |
105-130 |
140-152 |
165-219 |
203-350 |
||||||||
|
Hammer Length(mm) |
1034 |
1098 |
1372 |
1504 |
||||||||
|
Outside Dia.(mm) |
98 |
124 |
152 |
180 |
||||||||
|
Weight(kg) |
39 |
70 |
92 |
230 |
||||||||
|
Working Pressure(Mpa) |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
0.8-2.1 |
||||||||
|
Air Consumption (M3/Min.) |
3.5-15 |
4.5-18 |
9-26 |
9.6-24.8 |
||||||||
|
Torque(N.M) |
335 |
800 |
1150 |
1870 |
||||||||
|
Impact Frequency (Times/Min.) |
≥800 |
840-1500 |
950-1650 |
1100-1550 |
||||||||
|
Connection 1 |
API 2-3/8 |
API 2-3/8 |
API 3-1/2 |
API 4 1-2 |
||||||||
|
Connection 2 |
64-8 |
84-8 |
99.5-8 |
128-10 |
||||||||
