Customized Greenhouse Use Water Loop Heat Pump

Customized Greenhouse Use Water Loop Heat Pump thumbnail-1
Customized Greenhouse Use Water Loop Heat Pump thumbnail-2
Customized Greenhouse Use Water Loop Heat Pump thumbnail-3
Customized Greenhouse Use Water Loop Heat Pump photo-1
Customized Greenhouse Use Water Loop Heat Pump photo-2
Customized Greenhouse Use Water Loop Heat Pump photo-3
US$ 1,200 - 2,400 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Other, Water Source Heat Pump, water cooled
Installation:
Other, Freestanding, Ceiling installation
Storage / Tankless:
Instant / Tankless
Contact Supplier Request Quote Chat Now
Shenzhen Jinhuali Refrigeration Plant Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Water Source Heat Pump, water cooled
Installation Other, Freestanding, Ceiling installation
Storage / Tankless Instant / Tankless
Housing Material Other, galvanized sheet
Use Other, Villa, greenhouse plant
Certification CE
Place of Origin Guangdong, China
Brand Name HUALI
Model Number HLLS~10H

  Water to water heat pump/Water loop heat pump

Features

Integral type water source heat pump

The integral type water source heat pump with integrated design.It has thin body and does not need refrigerant condensing tube. Design and installation more convenient, higher safety and environmental protection, is ideal for high-grade comfortable space



Energy efficient

The integral type water source heat pump, using the world's leading high-performance compressor refrigeration system design and optimization, energy efficiency average of 4.5 or more, part of the national energy certification unit



Low noise level

Optimized refrigeration piping design and multiple quiet technology, which greatly limits to reduce air conditioning operating noise



Easy installation

Overall horizontal water source heat pump with compact body saves installation space, the unit comes with automatic fault diagnosis function, so that post-maintenance easier

Specification
 Model   HLLS-03H HLLS-04H HLLS-05H HLLS-06H HLLS-07H HLLS-10H HLLS-15H
 Power supply   220V/50Hz 380V/50Hz
 Cooling capacity kw 3.010 3.900 5.442 6.495 7.330 10.560 14.860
 Heating capacity kw 3.137 4.260 5.775 7.090 8.180 11.955 19.580
  Cooling Power input kw 0.725 0.982 1.389 1.734 1.930 2.330 3.750
 Heating Power input kw 0.772 1.085 1.495 1.849 2.122 2.330 4.400
 Cooling current A 3.4 4.6 6.6 8.3 9.7 11.6 6.100
 Heating current A 3.6 5.1 7.1 8.9 410.6 11.6 7.0
 Airflow volume m3/h 500 800 950 1100 1260 2030 2500
 External Static Pressure Pa 30(0,15,50,60) 80(30,50,100,120)
 Water flow volume m3/h 0.64 0.85 1.17 1.46 1.61 2.12 3.10
 Water pressure drop kPa 12.8 29 16.3 23.9 31.5 43.8 33.7
  Connected pipe in Rc3/4''

Unit noise level (H/M/L)		 dB(A) 40/39/38 41/40/39 43/42/41 44/43/42 45/44/43 47/46/45 48/47/46
 Evaporator Type Double Tube type Heat Exchanger
Compressor Type Rotary Scroll
Refrigerant Type R410A

Dimensions 		 Length mm 830 830 1024 1024 1024 1124 1313
Width mm 531 531 592 592 592 650 747
Height mm 382 382 436 436 436 510 512
Unit Weight kg 55 57 82 84 88 111 155



Model   HLLS-16H HLLS-18H HLLS-22H HLLS-30H HLLS-32H HLLS-38H HLLS-43H
 Power supply 380V/50Hz
 Cooling capacity kw 15.880 18.900 21.500 28.600 31.600 37.500 43.000
 Heating capacity kw 20.900 22.200 25.300 37.000 42.500 51.000 58.000
  Cooling Power input kw 4.070 4.540 5.500 7.400 8.030 9.530 11.150
 Heating Power input kw 4.700 5.100 6.100 8.600 8.780 11.030 13.190
 Cooling current A 9.4 8.7 9.7 15.2 15.8 17.8 21.6
Heating current A 10.2 9.5 10.5 16.4 16.5 19.9 23.2
 Airflow volume m3/h 2650 3500 4000 5200 6000 7000 8000
 External Static Pressure Pa 80(30,50,100,120) 80(100,120,150) 120(80,150,200) 150(100,200,250)
Water flow volume m3/h 3.40 4.20 4.80 6.40 7.00 8.30 9.50
 Water pressure drop kPa 35.3 50 60 42 50 54 85
 Connected pipe in Rc3/4'' R1-1/4''

Unit noise level (H/M/L)		 dB(A) 49/48/47 49 50 52 54 55 57
Evaporator Type double tube type heat exchanger
Compressor Type Scroll
Refrigerant Type R410A

Dimensions 		 Length mm 1313 1376 1376 1808 1808 2059 2059
 Width mm 747 852 852 1100 1100 1110 1110
 Height mm 512 592 592 720 720 737 737
 Unit Weight kg 158 178 180 330 340 370 380



Product show

   Customized greenhouse use water loop heat pumpCustomized greenhouse use water loop heat pump

Installation instruction



Customized greenhouse use water loop heat pump



Our Customer

About our certification

Company profile

Shenzhen Jinhuali Technology Co.,Ltd. is a modern large enterprise, which integrates technology, industry and trade. It is a professional enterprise that provides central A/C, refrigeration plant, eletromechanical device, electric equipment and electronics, as engineering design and installation service. HUALI takes an area of over 100,000m2  with an asset of more than 100 millions and empolyee of more than 500 persons, and its has 5 branch companies in the rest of China.
