Ceiling, Floor-Type Fan Coil Unit Manufacturer,highl Quality Floor Standing Fan Coil
US$ 225 - 420
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Huali
Model Number:
HLC-51F~238F, HLC-102F
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4 Pipe Ceiling Ducted Fan Coil Unit With Plenum BoxUS$ 75 - 199MOQ: 1 Unit -
Horizontal Concealed Water Ceiling Fan Coil Unit for Water Chiller / Heat PumpUS$ 70 - 245MOQ: 1 Piece
-
Huali Cassette Ceiling Type Water Chiller Fan Coil UnitUS$ 1 - 300MOQ: 1 Unit
-
European Type Vertical Fan Coil UnitUS$ 100 - 500MOQ: 1 Unit
-
Ceiling Fan Coil Unit Horizontal Concealed Fan Coil UnitUS$ 70 - 245MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Huali
Model Number
HLC-51F~238F, HLC-102F
Type
Air Conditioning
Ceiling, Floor-Type Fan Coil Unit manufacturer,highl quality floor standing fan coil
| Ceiling, Floor-Type Fan Coil Unit | |||||||||
| ModelHLC~ | 51F | 68F | 85F | 102F | 136F | 170F | 204F | 238F | |
|
Cooling capacity |
W | 2700 | 3600 | 4500 | 5400 | 7200 | 9000 | 10800 | 12600 |
| BTU | 9215 | 12287 | 15359 | 18430 | 24574 | 30717 | 36860 | 43004 | |
|
Heating capacity |
W | 4050 | 5400 | 6750 | 8100 | 10800 | 14500 | 16200 | 18900 |
| 1.50 | 1.50 | 1.50 | 1.50 | 1.50 | 1.61 | 1.50 | 1.50 | ||
| BTU | 13823 | 18430 | 23038 | 27645 | 36860 | 49489 | 55291 | 64506 | |
| Input power | W | 50 | 58 | 72 | 110 | 126 | 150 | 170 | 198 |
| Current | A | 0.225 | 0.258 | 0.32 | 0.49 | 0.561 | 0.68 | 0.82 | 0.882 |
| Power supply | V/P/Hz | 220-240V/1/50-60Hz | |||||||
| Fan motor QTY | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Air flow volume | m3/h | 510 | 680 | 850 | 1020 | 1360 | 1700 | 2040 | 2380 |
| Noise | dB(A) | 39 | 41 | 43 | 45 | 46 | 48 | 50 | 52 |
| Control way | Remote or wall pad | ||||||||
| Cooling Water flow | m3/h | 0.52 | 0.62 | 0.86 | 0.98 | 1.22 | 1.58 | 1.92 | 2.1 |
|
Cooling Water resistance |
Kpa | 14 | 16 | 18 | 22 | 25 | 39 | 44 | 44 |
| Drain pipe size | mm | 26 | |||||||
|
Connecting pipe (in) |
ZG3/4" | ||||||||
|
Connecting pipe (out) |
ZG3/4" | ||||||||
| Connecting way | Socket | ||||||||
| Dimensions | mm | 917*671*240 | 1289*671*240 | 1689*671*240 | |||||
| Weight | kg | 31 | 31 | 31 | 41 | 41 | 46 | 46 | 46 |
Note:
1. Cooling: Indoors DB 27°C,WB 19.5°C; Chilled water inlet/outlet temp. 12°C/7°C.
2. Heating: Indoors DB WB 21°C, heating water inlet&outlet temperature 60°C/50°C;
3.The noise level based on: background noise 11.5Db(A) semi-anechoic room.
4. Water resitance refers to that of rated water flow volume; 5. Input power refers to that of High speed air flow;
6. Above parameters are for your reference to model choice of FCU with cooling and heating; Heating energy of one row is 40% of three rows'; Low static pressure air flow volume loss: 10%, high static pressure air flow volume loss: 20%.
