FA467E/FA468E Roving Frame Machine

  FA467E/FA468E roving frame machine

1,the use of the products.

 spinning of cotton and man-made fibers,synthetic fibers shorter than 51 mm. In the spinning process,combed drawn slivers can

be converted int different count and different twist roving conveyed to the spinning frame.

 2.1 technical parameters:

 A.suitable fiber length(mm)22-51

 B. Yarn count(tex ):238-1250(0.8-4.2 Nm)

 C. Twist range :(t/m)16-81

 D. Total draft 4.668-1.77

 E. spindle speed: maximum of working speed  FA467E -1300r/min   FA468E-1300r/min

 Maximum of designing speed FA467E:1500r/min;FA468E:1500r/min.

 2.2. Specifications

1. A. Spindle gauge:FA467E: 220mm  FA468E: 194mm
2. B. Package dimension:FA467E:∅150X406mm; FA468E:∅135X406mm;
3. C. Draft system:4-roller with double short aprons
4. D. Weight system

   Weighting type:back-locked spring weighting arm YJ4-190x4,PK1500-001938 and arm HP-a410 and pneumatic arm PK5052 are available.(table 2-1)

G. Bottom the gauge : the maximum between the front and the back is 190mm

H. Roller stand inclination :15°

I. Spindle number :FA467E: 96  108  120  132    FA468E: 96  108  120  132

J. Clean positively revolving nap cloth for top and bottom rollers as well as blower and sucking device.

K. Winding system:

 Flyer :closed suspend flyers.

 Transmission style:with helix-gears

 Speed adjustment:computer  controlling the frequency and automatically

Feeding creel: the sliver roller of gantry feeding creel are transmitted with chain;the diameter of the feeding

can is ∅508mm/∅457mm/∅406mm.

M. Motor power

Flyer motor:              7.5kw

Bobbin motor:           7.5kw

Roller motor:                3kw

Lifter motor:                 3kw

Moving clean motor:  1.5kw

Suction motor :          3kw

Total power :             25.5kw

N. Automatic stop: adopting photoelectrical automatic stop device

Yellow :two lines for breakage of yarns and two lines for safety protection

Blue: one line of breakage of yarns

White: full package

P.machine specifications(mm)

Beam height: 1400

Beam width: 3535(including 6 creels)

The machine head width:965

The machine head height:1800(not including the instruction light)

The machine head length: 1182-14522

Q1: What’s the kind of your company?

A1: We are factory with more than 16 years production experience. Also we have professional internation salesman which give you best service. Any question will be replied within 24 hours.

A2: Our factory is located in shijiazhuang City,hebei of China. You can take flight to shijiazhuang  airport, and we can pick you up there.

Q3: What is the Key part  of your products?

A3:  High precision roller, High speed spindle and Reliable CCD closed loop control tension to ensure the quality of spinning

Q4: What’s your lead time?

A4: 15-20 days against formal order and deposit.

Our survice:

1) We are manufacture with professional production team and skilled technical.

2) Knowledgeable design & engineering staff to help satisfy your unique requirements.

3) Balance to quality and cheap price, commitment to finding a workable, cost- effective solution for every customer.

4)  variety of colors and designs are available.

5) Felixable delivery time as your requirement.

6) We are able to actively respond to other different styles of customized demand.

7) 24 hours on mobilephone and email.
