Help CenterCE Manufacturer Good Quality Coffee Color Sorting Machine
Related Products
-
Coffee Bean Sorting Machine Color Seperate MachineUS$ 18,000 - 70,000MOQ: 1 Unit -
Hot Sale Brazil Coffee Bean Color Sorting MachineUS$ 10,000 - 40,000MOQ: 1 Unit
-
New Model Coffee Bean Color Sorter Grain Color Sorting MachineUS$ 18,000 - 70,000MOQ: 1 Unit
-
New Generation CCD And LED Coffee Bean Color Sorter With Trade AssuranceUS$ 18,000 - 70,000MOQ: 1 Unit
-
Simple Operate Grain Color Sorter With High Speed EjectorUS$ 18,000 - 70,000MOQ: 1 Unit
Color sorter machine accordind to the shape and color difference, give product classified and selected.
Now are widely used in coffee area, bring more profit .
Coffee color sorting machine technical Parameter
| Model | Z2-128 | Z3-192 | Z4-256 | Z5-320 |
| Type | 6SXZ-128 | 6SXZ-192 | 6SXZ-256 | 6SXZ-320 |
| Output(t/h) | 1.5-4 | 3-6 | 5-10 | 6-10 |
| Sorting Accuarcy(%) | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 |
| Carryover Rate (Bad:Good) | ≥10:1 | ≥10:1 | ≥10:1 | ≥10:1 |
| Weight(kg) | 600 | 700 | 800 | 900 |
| Resolution(mm²) | 0.04 | 0.04 | 0.04 | 0.04 |
| Power(kw) | 1.5 | 2 | 2.5 | 3 |
| DimensionLxWxH(mmxmmxmm) | 1370x1650x2010 | 1684x1650x2010 | 1998x1650x2010 | 2312x1650x2010 |
| Power Supply(V/Hz) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
| Model | Z6-384 | Z7-448 | Z10-640 | Z12-768 |
| Type | 6SXZ-384 | 6SXZ-448 | 6SXZ-640 | 6SXZ-768 |
| Output(t/h) | 7-12 | 8-15 | 13-24 | 18-30 |
| Sorting Accuarcy(%) | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 |
| Carryover Rate (Bad:Good) | ≥10:1 | ≥10:1 | ≥10:1 | ≥10:1 |
| Weight(kg) | 1000 | 1100 | 1400 | 1600 |
| Resolution(mm²) | 0.04 | 0.04 | 0.04 | 0.04 |
| Power(kw) | 4 | 4.5 | 6 | 8 |
| DimensionLxWxH(mmxmmxmm) | 2626x1650x2010 | 2930x1650x2010 | 4100x1650x2010 | 2670x3000x2010 |
| Power Supply(V/Hz) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
1.The above data is based on the 2% contamination, and real output depends on the material and its contamination.
2.If products update, no further notice. Please refer to the real machine.
Advantage :
1. More high-end 4096 IPIEX CCD camera, can distingush flaw which are less than 0.04 mm², glasses and resin etc, increase sorting impression to a higher level.
2. Scientific and resonable optics-design, more clear for light yellow, distinguish wider rang.
3. Reasonable heat output device, ensure all spare parts be working in the room tepurature, SNR is better, not only increased the accuracy of sorting, but also extended the life of machine.
4. More intelligent software, can distingush all kinds of heterochrosis grain easily and totally improved the accuracy of selection.
5. Humanization ture colour screen, visual effect is more clear, operation is more easiler.
6. Professinal high frequency ejectors, save more air, reaction velocity is more quick, rate of accuracy is higher, and longer life, working with intelligent software, ensure the good rejection and excellent accuracy.
More related color sorter
1. How about engineers service oversea?
Engineers available to service machinery overseas.
2. How to use the machine?
We will supply customer the installation catalog or video online.
We will ask our engineer to teach you, how to use when he go to your country to debug the machine.
3. How about the sample machines for testing?
Sample sending for testing is welcomed.
Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to
discard). we send our video to you.
4. How about the guarantee period?
One year.
5. Will you accept L/C as payment?
L/C ,T/T is OK .
Alibaba Trade Assurance is your best choice.
6.Do you have any other spare parts for the customer?
Yes,we will supply you some spare parts .
7.Which machine will work together with our color sorter which you can supply?
Air compressor ,Air tank ,Air filters,Air dryer , light sources, cleaning brushes, etc.
1.We show our presence in China and around the globe.
2.We adhere to the principle of Customer priority, encourage employees to care about customer demand, and provide solutions for both domestic and overseas customer.
3.We have over 30 after-sale service staff, with our service penetrating to prefecture-level city, and provide 24h door-to-door prompt and thoughtful service for customers.
4.We provide customer with one year free repair and maintenance for complete machine, and prompt professional training and technical guidance, which fully embodies our service mode featuring fast response, timely maintenance and follow-up coordination.
Service commitment: One year free repair and maintenance for complete machine, 24h door-to-door fast response, 7x24h consultation service,
Establish user file for follow-up service.
1. plywood case for each color sorter.
2. we will arrange the shipment as soon as possible, Gernearally speaking ,we will arrange the shipment in 15 days after we receive the deposit.
