Help CenterBig Capacity Wolfberry / Medlar Color Sorter Food Processing Machine
Related Products
-
Good Performance LED White Kidney Bean Cereal Color Sorter MachineUS$ 15,000 - 70,000MOQ: 1 Unit -
Factory Direct Supply White Kidney Bean Nut Color Sorter MachineUS$ 9,999 - 49,999MOQ: 1 Unit
-
High Efficiency CCD White Kidney Bean Color Sorter Machine Grain Color SorterUS$ 18,000 - 70,000MOQ: 1 Unit
-
China Manufacturer White Kidney Bean Color Sorting MachineUS$ 18,000 - 70,000MOQ: 1 Unit
-
Digital Wolfberry Color Separation Machine in ChinaUS$ 15,000 - 50,000MOQ: 1 Unit
Core Technology
CCD color sorter technical Parameter
| Model | Z2-128 | Z3-192 | Z4-256 | Z5-320 |
| Output(t/h) | 0.5-2 | 1.0-4.0 | 1.5-5.0 | 2.0-6.0 |
| Sorting Accuarcy(%) | ≥99 | ≥99 | ≥99 | ≥99 |
| Carryover Rate (Bad:Good) | ≥8:1 | ≥8:1 | ≥8:1 | ≥8:1 |
| Wegiht(kg) | 600 | 700 | 800 | 900 |
| Resolution(mm²) | 0.04 | 0.04 | 0.04 | 0.04 |
| Power(kw) | 1.5 | 2 | 2.5 | 3 |
| DimensionLxWxH(mmxmmxmm) | 1370x1650x2010 | 1684x1650x2010 | 1998x1650x2010 | 2312x1650x2010 |
| Power Supply(V/Hz) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
| Model | Z6-384 | Z7-448 | Z10-640 | Z12-768 |
| Output(t/h) | 2.5-7.0 | 3.0-8.0 | 4.5-11 | 6-13 |
| Sorting Accuarcy(%) | ≥99 | ≥99 | ≥99 | ≥99 |
| Carryover Rate (Bad:Good) | ≥8:1 | ≥8:1 | ≥8:1 | ≥8:1 |
| Weght(kg) | 1000 | 1100 | 1400 | 1600 |
| Resolution(mm²) | 0.04 | 0.04 | 0.04 | 0.04 |
| Power(kw) | 4 | 4.5 | 6 | 8 |
| DimensionLxWxH(mmxmmxmm) | 2626x1650x2010 | 2930x1650x2010 | 2930x1650x2024 | 2930x1650x2024 |
| Power Supply(V/Hz) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
1.The above data is based on the 3% contamination, and real output depends on the material and its contamination.
2.If products update, no further notice. Please refer to the real machine.
Color sorter structure schematic
Wolfberry / Medlar color sorting example
More related color sorters
1. How about engineers service oversea?
Engineers available to service machinery overseas.
2. How to use the machine?
We will supply customer the installation catalog or video online.
We will ask our engineer to teach you, how to use when he go to your country to debug the machine.
3. How about the sample machines for testing?
Sample sending for testing is welcomed.
Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to
discard). we send our video to you.
4. How about the guarantee period?
One year.
5. Will you accept L/C as payment?
L/C ,T/T is OK .
Alibaba Trade Assurance is your best choice.
6.Do you have any other spare parts for the customer?
Yes,we will supply you some spare parts .
7.Which machine will work together with our color sorter which you can supply?
Air compressor ,Air tank ,Air filters,Air dryer , light sources, cleaning brushes, etc.
