Home > Products > Tea > ZRWS automatic intelligent tea color sorter/tea separator machine/tea color sorting machine

Share|

ZRWS automatic intelligent tea color sorter/tea separator machine/tea color sorting machine

Name: ZRWS automatic intelligent tea color sorter/tea separator machine/tea color sorting machine
Brand: ZRWS
Price: USD $16,889 - 17,389 / Set

FOB Price

USD $16,889 - $17,389 / Set

1 Set(Min.Order)

Supply Ability 50 Piece / Pieces per Month
Port Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Guangdong, China	Brand Name:	ZRWS
Model Number:	6CSX-68B	Production Capacity:	40kg-100kg	Voltage:	220V 50Hz
Power(W):	1.2-1.6(Kw)	Weight:	400(Kg)	Dimension(LWH):	103519342223mm
Certification:	CE/SONCAP	Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

ZRWS automatic intelligent tea color sorter/tea separator machine/tea color sorting machine

Application

SPECIFICATIONS
Type		6CSX-68B
Carryover ratio(bad:good)		6:1
Capacity(T/H)		40-100
Sorting precision(%)		99%
Voltage		220V/50HZ
Power（kw）		1.2-1.6
Air Pressure（Mpa）		0.5-0.7
Air Consumption（L/min)		≤1800

Advantages

5388 pixel high-resolution line scan CCD image sensor allows to identify any defects with subtlest color variation.

Intelligent algorithms colors shapes,digital information processor decicated for powerful industrial control,high intelligent image processing algorithms dedicated for color sorter.High-speed capture,high-speed processing,which improves the consistency of the signal path and stability and reliability of the system,thus to ensure the sorting effect.

Wireless Panel PC remote Operating system. 12 inch panel PC and android 4.4 operating system. Humanized operation screen is user-friendly.

Use High-quality,high-frequency,up to 1200 HZ per second. The fastest response time within 0.6 ms .long service life ejector ,service time 5-10 billion. excellent rejection output .

Special customized aluminum alloy materials , non-toxic, harmless ,which meets the standard of international food safety .Rust proof material is unique for materials, super-wide design, feed smoothly and reduce materials waste, sort more precisely and larger capacity.

Shadowless LED lighting system allows the most precise focusing of the beam on the inspection line.The LED white light be able to apply to all the materials.

Tilting optical boxes,to allow an easy internal access for maintenance operation.

Automatic cleaning system,with adjustable frequency and duration.

Interactive remote control

Reject & Accept

Operation

Input product is loaded into the in-feed hopper (1), it moves along the vibrating plate (2), until it flows on to a sloping chute (3), where it is individually checked at 360° and sorted by RGB-Full color cameras (4) . Depending on the signals received by the optical device, the sorter software controls the pneumatic device (6), which physically separates the unwanted products out of the conforming ones, which naturally reach their discharging hopper (8). The rejected products are instead deviated by a jet of compressed air produced by the relevant ejector and discharged in the front side hopper (9). In automatic resort versions, the sorted or rejected product to be conveyed to another section of the machine to undergo an identical process.

Packing & Delivery

Packaging
Size(mm)	1035119342223mm
Weight	400KG
Packaging Details	Export wooden packing .

If you have any interesting, pls feel free to contact with me:

Skype: kenny12034

WeChat: yongqing1203
Tel:+86-755-23724040
Mobile:+86 158 18595425(whatsapp)

About Us

We specialize in color sorter R&D and production basis on independent technology development,having the leading technology in intelligent color sorter. Located in XinLong industrial park ShaJing town, BaoAn district, ShenZhen China,with an area of 16,000 square meters. As the largest color sorter equipment manufacture base in south China, we have the top-level color sorter technical team worked in Europe and America for years. We make great efforts to explore and lead the development of color sorter technology.

At present,our products include rice color sorter,grains color sorter,nuts color sorter,cereals color sorter ,beans color sorter, seeds color sorter ,tea color sorter, Color Sorters for Industrial products and Belt Color Sorter .Our products meet the demands of color sorting in many industries.
