Parboiled rice selecting machine

5388 pixel high-resolution line scan CCD image sensor allows to identify any defects with subtlest color variation.

Intelligent algorithms colors shapes,digital information processor decicated for powerful industial control,high intelligent image processing algorithms dedicated for color sorter.High-speed capture,high-speed processing,which improves the consistency of the signal path and stability and reliability of the system,thus to ensure the sorting effects.

Wireless Panel PC remote Operating system. 12 inch panel PC and android 4.4 operating system. Humanized operation screen is user-friendly.

Use High-quality,high-frequency,up to 1200 HZ per second. The fastest response time within 0.6 ms .long service life ejector ,service time 5-10 billion. excellent rejection output .

Special customized aluminum alloy materials , non-toxic, harmless ,which meets the standard of international food safety .Rust proof material is unique for materials, super-wide design, feed smoothly and reduce materials waste, sort more precisely and larger capacity.

Shadowless LED lighting system allows the most precise focusing of the beam on the inspection line.The LED white light be able to apply to all the materials.

Tilting optical boxes,to allow an easy internal access for maintenance operation.

.

Automatic cleaning system,with adjustable frequency and duration.

Interactive remote control

Input product is loaded into the in-feed hopper (1), it moves along the vibrating plate (2), until it flows on to a sloping chute (3), where it is individually checked at 360° and sorted by RGB-Full color cameras (4) . Depending on the signals received by the optical device, the sorter software controls the pneumatic device (6), which physically separates the unwanted products out of the conforming ones, which naturally reach their discharging hopper (8). The rejected products are instead deviated by a jet of compressed air produced by the relevant ejector and discharged in the front side hopper (9). In automatic resort versions, the sorted or rejected product to be conveyed to another section of the machine to undergo an identical process.
