Opto Electronic Grain Color Sorter Machine Grain Processing Machine

Shenzhen Zhongruiweishi Optoelectronic Co., Ltd.
Opto Electronic Grain Color Sorter Machine Grain Processing Machine thumbnail-1
Opto Electronic Grain Color Sorter Machine Grain Processing Machine thumbnail-2
Opto Electronic Grain Color Sorter Machine Grain Processing Machine photo-1
Opto Electronic Grain Color Sorter Machine Grain Processing Machine photo-2
US$ 34,366 - 34,666 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ZRWS
Model Number:
6SXZ-612
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ZRWS
Model Number 6SXZ-612
Type Grain Processing Equipment
After-sales Service Provided Engineers available to service machinery overseas
Product Description
Opto Electronic Grain Color Sorter Machine Grain Processing Machine
SPECIFICATIONS
Type
6SXZ-612
Carryover ratio(bad:good)
10:1
Capacity(T/H)
6-10
Sorting precision(%)
99%
Voltage
220V/50HZ
Power（kw）
3.6-5.0
Air Pressure（Mpa）
0.6-0.8
Air Consumption（L/min)
≤5600
Advantages



5388 pixel high-resolution line scan CCD image sensor allows to identify any defects with subtlest color variation.




Intelligent algorithms colors shapes,digital information processor decicated for powerful industial control,high intelligent image processing algorithms dedicated for color sorter.High-speed capture,high-speed processing,which improves the consistency of the signal path and stability and reliability of the system,thus to ensure the sorting effects.




Wireless Panel PC remote Operating system. 12 inch panel PC and android 4.4 operating system. Humanized operation screen is user-friendly.





Use High-quality,high-frequency,up to 1200 HZ per second. The fastest response time within 0.6 ms .long service life ejector ,service time 5-10 billion. excellent rejection output .



Special customized aluminum alloy materials , non-toxic, harmless ,which meets the standard of international food safety .Rust proof material is unique for materials, super-wide design, feed smoothly and reduce materials waste, sort more precisely and larger capacity.




Shadowless LED lighting system allows the most precise focusing of the beam on the inspection line.The LED white light be able to apply to all the materials.




Tilting optical boxes,to allow an easy internal access for maintenance operation.




Automatic cleaning system,with adjustable frequency and duration.




Interactive remote control


Operation

1.Product in-feed hopper
2.Vibrating plate
3.Sloping chute
4.full-color RGB CCD cameras
5.Reflector panel
6.Ejector
7.Control box
8.Discharging hopper for sorted product
9.Reject products discharging hopper.
10.DPS


Packing & Delivery
Packaging
Size
3810(L)*1630(W)*2200(D)
Weight
1770KG

Packaging
Details

Export wooden  packing.
About us

    We specialize in color sorter R&D and production basis on independent technology development,having the leading technology in intelligent color sorter. Located in XinLong industrial park ShaJing town,BaoAn district,ShenZhen China,with an area of 16,000 square meters.As the largest color sorter equipment manufacture base in south China,we have the top-level color sorter technical team worked in Europe and America for years.We make great efforts to explore and lead the development of color sorter technology.

Our customers

Contact us
Related Products

color sorter manufacture factory millet color sorter
