Excellent Quality CCD Bean Color Sorter

Excellent Quality CCD Bean Color Sorter thumbnail-1
Excellent Quality CCD Bean Color Sorter thumbnail-2
Excellent Quality CCD Bean Color Sorter thumbnail-3
Excellent Quality CCD Bean Color Sorter thumbnail-4
Excellent Quality CCD Bean Color Sorter thumbnail-5
Excellent Quality CCD Bean Color Sorter thumbnail-6
Excellent Quality CCD Bean Color Sorter photo-1
Excellent Quality CCD Bean Color Sorter photo-2
Excellent Quality CCD Bean Color Sorter photo-3
Excellent Quality CCD Bean Color Sorter photo-4
Excellent Quality CCD Bean Color Sorter photo-5
Excellent Quality CCD Bean Color Sorter photo-6
US$ 23,000 - 24,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ZRWS
Model Number:
6SXZ-272
Contact Supplier Request Quote Chat Now
Shenzhen Zhongruiweishi Optoelectronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ZRWS
Model Number 6SXZ-272
Type Grain Processing Equipment
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Application

ZRWS bean color sorter has the ability to sort out all the visible defects,such as dirty,moldy,spotted,stone,shriveled. Make homogeneous appearance of final products.

SPECIFICATIONS
Type
6SXZ-272
Carryover ratio(bad:good)
10:1
Capacity(T/H)
2-2.5
Sorting precision(%)
99%
Voltage
220V/50HZ
Power（kw）
1.8-3.0
Air Pressure（Mpa）
0.6-0.8
Air Consumption（L/min)
≤3200
Reject & Accept
Advantages
Operation

1.Product in-feed hopper
2.Vibrating plate
3.Sloping chute
4.full-color RGB CCD cameras
5.Reflector panel
6.Ejector
7.Control box
8.Discharging hopper for sorted product
9.Reject products discharging hopper.
10.DPS


Input product is loaded into the in-feed hopper (1), it moves along the vibrating plate (2), until it flows on to a sloping chute (3), where it is individually checked at 360° and sorted by RGB-Full color cameras (4) . Depending on the signals received by the optical device, the sorter software controls the pneumatic device (6), which physically separates the unwanted products out of the conforming ones, which naturally reach their discharging hopper (8). The rejected products are instead deviated by a jet of compressed air produced by the relevant ejector and discharged in the front side hopper (9). In automatic resort versions, the sorted or rejected product to be conveyed to another section of the machine to undergo an identical process.


Packing & Delivery
Packaging
Size
2110(L)*1630(W)*2200(D)
Weight
970KG

Packaging
Details

Export wooden packing.
About us

We specialize in color sorter R&D and production basis on independent technology development,having the leading technology in intelligent color sorter. Located in XinLong industrial park ShaJing town,BaoAn district,ShenZhen China,with an area of 16,000 square meters. As the largest color sorter equipment manufacture base in south China, we have the top-level color sorter technical team worked in Europe and America for years. We make great efforts to explore and lead the development of color sorter technology.
At present,our products include rice color sorter,grains color sorter,nuts color sorter,cereals color sorter ,beans color sorter, seeds color sorter ,tea color sorter, Color Sorters for Industrial products and Belt Color Sorter .Our products meet the demands ofcolor sorting in many industries
