High-Speed Multifunctional Color Sorting Machine, CCD Rice Color Sorter

Name: High-Speed Multifunctional Color Sorting Machine, CCD Rice Color Sorter
Brand: MINGDER
Availability: InStock

FOB Price

USD $33,600 - $72,800 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China	Brand Name	MINGDER
Model Number	MS-M320	Type	Grain Processing Equipment
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

CCD Sensor rice color sorter machine:
1. Carryover 20:1
2.High Sensitivity
3.High Accuracy 99.99%
4.High Stability

5.High output

RICE COLOR SORTER Machinery

cereal grading machinery

plastic color sorter

peanut color sorter

coffee bean color sorter

raisin color sorter

SORTING MACHINE Type Wheat Grain Color Sorter

agricultural products sorting equipments

rice processing machines and Color Sorter of MINGDER CORPORATION/ Rice Milling Machine

========================================================================================

Specifications

Advanced optical color sorter for rice.

Advanced optical color sorter for rice:

Available in 4, 5, 6, 7 chutes (lanes), 256, 384, 448 channels for small to large capacity requirements.

Sorting accuracy at the speed of light:

Using Mingder-designed cameras, products are scanned 8,000 times per second, creating sorting accuracy that is unachievable by any other method. Images are converted using high speed, 2,048 pixel monochromatic, high-resolution CCD technology, for extreme accuracy in detecting even the smallest defects.

Two cameras per tray, mounted on the front and rear for dual-side viewing of your product.
Designed by Mingder engineers, the new generation Digital Signal Processor operates at optimal data processing speed. Sophisticated sorting algorithms create maximum sorting efficiencies, and there is virtually no time delay between defect signal and ejector activation.

Ejectors that define durability and reliability:

Delta's patented, high-speed pneumatic ejectors are machined to the highest tolerances in the industry.

Precision manufacturing, special metal alloys and custom hardening techniques produce an ejector with an exceptionally long life.
Minimizes maintenance downtime and costs.
Ejector array is highly concentrated for the greatest sorting accuracy and minimal loss of good product.

The world's friendliest optical sorter:

The CCD series continues the Mingder philosophy of making operation easy and intuitive.

Pre-set sorting mode provides fast setup for different products.
Automatic calibration for fast and easy setups.
Fault detection system within each sorter for easy and rapid diagnostics.
Unique pulse width modulation (PWM) feeders ensure a constant feed of product and reduce power consumption by 15-20%.
Large, easy-to-read LED full color touch screen.

Mingder's reliability and service assurance:

Highly trained Mingder technicians assist customers with sorter specifications, options, start up and on-site training.
Each sorter has its own fault detection system for immediate diagnostics.
Long life precision ejectors minimize maintenance costs.
Feeder trays have aircraft coating for durability and minimal friction.
Advanced LED illumination system with no frequent changeover of lamps required and low power consumption.
Worldwide experience and world class service since 2008. Local service is available in most countries or regions.

===================================================================================================

Our Testing STAGE:

Rice Color Sorter

ITEM: Rice Color Sorter
Model NO: MS-M
Feature: CCD

1. Leading LED light source technology,featured with high efficiency, long service life, strong anti-interference ability

2. Adapt 2048-pixel high-speed high resolution CCD sensor and high-precision camera lens;can accurately identify as small as 0.02 mm2 heterochromatic areas and easily identify light yellow, belly-white and small disease spots.

3. Adopt high-quality, high-frequency, Long service life, low air consumption, can guarantee maximum output, low carryover ratio and low failure rate.

4. The unique direct air ejector significantly reduces air resistance and air consumption, responds more quickly, and creates better aiming accuracy, can reduces carryover ratio as well.

5. The ARM+FPGA double core system can enable top-level computing and processing ability.

6. Specific optimum corresponding working mode designed for different kinds of rice, one machine can sort different kinds of rice.

7. New power supply system, low energy consumption, can reduce cost, and can help to avoid adverse effect caused by sudden voltage change, therefore to realize long-term stable operation.

8. Auto-self-detection function, can automatically detect faults of ejectors, pressure, control board and background board etc; therefore is user friendly and time, energy efficient.

9. Specially designed discharge system, can greatly reduce the product carryover.

10. Sealed control box can protect key components from dust, so the machine will few mechanical stoppage, and therefore to extend service life.

11. The powerful smart software operation system is easy to learn and to use. The colorful touch panel is user friendly and pleasant.

Technical parameters:

(Model NO.)		MS-M384		MS-M320		MS-M256
(Channels)		384		320		256
(T/H)Output		4~16		4~12		3~9
(%)(Accuracy)		≥99.99		≥99.99		≥99.99
(Optimal Carryover)		≥20:1		≥20:1		≥20:1
(Voltage) (V)		AC220V 50HZ		AC220V 50HZ		AC220V 50HZ
(KW) (Power)		3.3		3.0		2.2
(Mpa) (Air Pressure)		0.6~0.8		0.6~0.8		0.6~0.8
(KG) (Weight)		1400		1120		900
(L×W×H:MM) (Dimension)		290015002200		150021222200		150018502200
(Model NO.)	MS-M384		MS-M320		MS-M256
(LWH:MM) (Dimension)	290015002200		150021222200		150018502200

Note :

1. All the parameters listed above are worked out base on rice with 3% impurity, it may vary according to different targeted materials ,different impurities percentage or different output of each chute.

2. Update to the machine is allowed without notification. Please refer to the actual machine for more details.

Packaging & Shipping

Will pack according to the customers' requirements. tks

Our Services

Best after-sale service.

Set office overseas and online operation instruction & solution

24 hours online call service.

Hot line 4009600448

========================================

Diana Hong

My skype: dianahongsmile

Whatsapp: 008613966725592

Weichat: h624350311

Email: dianahong @

===================================

Company Information

Hefei MINGDE Photoelectric Technology CO,. Ltd is a professional smart-color-sorter equipment research, development and production enterprise, which is located in China, Shuangfeng Economic Development Zone of Hefei city; owns a 40 acres industrial park including 2000square meters R&D center and standard factory; has the capacity to produce more than thousand machines and to generate more than 100 million output value per year.

The R&D team of MINGDE consisted of innovative experts and talent in photoelectric technology field, most of whom are graduates from Tsinghua University, University of Science and Technology of China etc. The goal of MINGDE is to achieve maximum customer satisfaction by developing smart, practical, user friendly and high quality products. So far, MINGDE has launched a series of smart color sort machine, whose intellectual property rights are owned by MINGDE completely. This series of product can accurately sort food material such as rice, cereal, tea etc. and industrial material including plastic, mineral and so on, which are successfully exported to America, Africa, Southeast Asia and other overseas markets. All series of the products are well respected within photoelectric color sorting field and praised by customers.

In MINGDE, our enterprise philosophy is that “Integrity is the basis for successes”. We devote to the creation of leading technology and innovation. We are willing to work with friends from all areas and to make brilliant contributions in photoelectric color sorting field.

FAQ

What is our color sorters for ?

--For sorting your rice, grains, etc. material in good quality and rate

Do you have the warranty ?

--YES. We provide life-long time maintaining service. 1 year

What's the lead time ?

--About 10-20 working days according to your needs.

Do you acccept Custom-made order ?

--YES. WE DO ! We are manufacturer.

Engineers overseas service abailable ?

YES !

========================================
