Production description
The processing of shelled peanuts, peanuts kernels or blanched peanuts involves plenty of hand-picking, take time and high labor cost. The appearance of peanut color sorting machine offers a good solution to the above problems. The machine saves the labor cost, improves working efficiency and further solves a big headache of administration for management. At present our company peanut color sorters are in operation in many domestic regions and global markets like India and Africa, also have the presence of peanut sorters.
Mingder peanut color sorters can take off various defective kernels, for instance, peanut kernel in mould, peanut with bud, peanut in shell. For blanched peanuts, whether they are dry or wet peeling, Mingder color sorters are able to work on them, and belt machines have higher sorting effect and lower broken ratio compared with traditional chute-type sorters. Belt machines especially have great effect with shelled and fried peanuts. After sorting, peanuts are usually go straight for packing without hand.
Advantages of our rice color sorter
1.Power-saving
2.High Sensitivity
3.High Accuracy 99.99%
4.High Stability
5.High output
Color sorter/Rice color sorting equipment characteristics:
1. Power-saving. Individual host power supply system and separate heating, power supply can be selected to heat or not according to the work environment and room temperature. It can save about 2000usd/set per year.
2. High-resolution. Latest international first-class CCD 2048 Pixels double camera.
3. Imported Parts; Japan SMC filters, avoiding water, oil and small dust.
4. International brand valve core; International first-class imported valve core, ensure 3-5 times longer service time, higher accuracy and capacity than others. & high frequency solenoid valve, low carryout, less power, less air consumption.
5. First-class color sorting technology, both yellow and white color can be sorted separately.
6. Arm+FPGA double core hardware system, ensure the optimum algorithm processing.
7. Safe operation. Air pressure automatic detection system, can stop the feeding automatically..
8. GRB tri-color sorting technology, with high accuracy & perfect performance.
9. Leading LED full color light source, long service time.
10. Humanity interface, easy operation with colorful touch screen.
Technical specifications:
(Model NO.) | MS-Z 384 | MS-Z320 | MS-Z256 |
(Channels) | 384 | 320 | 256 |
(KG/H)(Output) | 5~18 | 4~15 | 4~10 |
(%)(Accuracy) | ≥99 | ≥99 | ≥99 |
(Optimal Carryover) | ≥10:1 | ≥10:1 | ≥10:1 |
(Voltage)(V) | AC220V 50HZ | AC220V 50HZ | AC220V 50HZ |
(KW)(Power) | 3.3 | 3.0 | 2.2 |
(Mpa)(Air Pressure) | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 |
(KG)(Weight) | 1700 | 1350 | 1150 |
(L*W*H:MM) (Dimension) | 2998*1550*1980 | 2660*1550*1980 | 2322*1550*1980 |
Packaging details:packed according to customers’ requirement.
Delivery details:10-20 working days afer reeeive advance payment.
1. Free installation and commissioning
2. Free maintance for one year
3. Set office overseas and online operation instruction & solution within 24 h
4. Long life free upgrading software.
Hefei MINGDE Photoelectric Technology CO,. Ltd is a professional smart-color-sorter equipment research, development and production enterprise, which is located in China, Shuangfeng Economic Development Zone of Hefei city; owns a 40 acres industrial park including 2000square meters R&D center and standard factory; has the capacity to produce more than thousand machines and to generate more than 100 million output value per year.
The R&D team of MINGDE consisted of innovative experts and talent in photoelectric technology field, most of whom are graduates from Tsinghua University, University of Science and Technology of China etc. The goal of MINGDE is to achieve maximum customer satisfaction by developing smart, practical, user friendly and high quality products. So far, MINGDE has launched a series of smart color sort machine, whose intellectual property rights are owned by MINGDE completely. This series of product can accurately sort food material such as rice, cereal, tea etc. and industrial material including plastic, mineral and so on, which are successfully exported to America, Africa, Southeast Asia and other overseas markets. All series of the products are well respected within photoelectric color sorting field and praised by customers.
In MINGDE, our enterprise philosophy is that “Integrity is the basis for successes”.
We devote to the creation of leading technology and innovation. We are willing to work with friends from all areas and to make brilliant contributions in photoelectric color sorting field.
What is our color sorters for ?
--For sorting your rice, grains, etc. material in good quality and rate
Do you have the warranty ?
--YES. We provide life-long time maintaining service.
What's the lead time ?
--About 10-20 working days according to your needs.
Do you acccept Custom-made order ?
--YES. WE DO ! We are manufacturer.
What is our color sorters for ?
--For sorting your rice, grains, etc. material in good quality and rate
Do you have the warranty ?
--YES. We provide life-long time maintaining service. 1 year FREE
What's the lead time ?
--About 10-20 working days according to your needs.
Do you acccept Custom-made order ?
--YES. WE DO ! We are manufacturer.
Engineers overseas service abailable ?
YES !
========================================
