forktedder for agriculture construction

Name: forktedder for agriculture construction
Brand: Kaida
Availability: InStock

FOB Price

US$ 3,500 - 20,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.Flexible steering and small turning radius, with full Hydraulic Steering System
2.chinese famous brand
3.good price

Rated elevating capacity	2000kg
Load center	500mm
Max unload height	1800mm
Lifting speed(speed/full)	470/450mm/s
Max. travelling speed	20km/h
Max. lifting speed	3000mm
Dip angle of portal(front/back)	6/12
Free lifting hight	135
Turn radius(external)	2300
Climbing capacity (full/ empty)	18/20%
Total length(expect fork)	2600mm
Total width (appearance)	1400mm
Total height (to canopy guard)	2220mm
Max. height of work	4030mm
Max. rate of decay	empty/550 full/450mm/s
Wheel base	1580mm
Tread of front wheels	1350mm
Tread of back wheels	970mm
Type of front tires	10-16.5
Type of back tires	650-10
Min. ground clearance(lowest)	140mm
Voltage of storage bettery	24v
launch braking/stop braking	hydraulic-foot rest/machine-hand brake lever
Engine	CF1130
Gear box	2-2 manual shirt T/M
Work pressure	16mpa
Height of portal(fork dropped)	2075mm
Fork(lengthwidththickness)	107012045mm
