1,Design, manufacture aluminum strip casting mill2,Products have been exported to Mid East
3,Can provide nonstandard produc
1. Technicial parameter of aluminum casting mill
Aluminum alloy | 1000,3000,8000 series |
Product thickness | 5-10 mm |
Max. Rolling force | 6000-25000kn |
Product width | 800-2200mm |
Length of roll surface | 1000-2400mm |
Dia. of casting roll | Φ600-1200mm |
Max. Coil weight | 20000kg |
Rolling speed | 800-1500 mm/min |
Electric control system | SIEMENS ABB |
Model type(aluminum strip casting mill) | Φ650~700×1400~1650 |
Φ720~850×1650~1850 | |
Φ960~980×1600~2100 | |
Φ1000~1200×1800~2400 |
2. aluminum casting mill components
No. | Components name | No. | Components name |
1 | Dual-channel devices given to titanium wire | 9 | Flame spraying system |
2 | caster mouth adjustment platform | 10 | Clip send roller device |
3 | caster set body |
11 | —Hydraulic servo cut |
4 | Casting roller parts | 12 | Partial derivative roll component |
5 | Caster roller drive system |
13 | Coiler |
6 | Pressure on fuel tank(adopt Guangzhou Institute of seal products) | 14 | Discharge dolly |
3. Aluminum casting mill advantages
A. Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control system (AGC).
B. Piecewise controlled cooling system .
C. Advanced pre-coated plate filtration system.
D. Automatic and manual controlled CO2 fire extinguishing system.
E. Full digital control and network communication, aim to provide control accuracy and reliability.
F. Advanced engineering workstations.
G. The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.
H. 12 inch color LCD operator terminals, easy to operate and display.
We are specialized in the design, manufacture & install of aluminum foil rolling mill, we supply kinds of auxiliary equipment and aluminum foil rolling mill accessories. We have a strong technical force, advanced production capacity and high quality after-sale service team. We can provide you product with comfortable price, great after-sale service.
For more information, please contact us directly. We hope to receive your detailed inquiries soon, and we are looking forward to having the chance of cooperating with you in the near future.
