Non-reversing 2000max m/min rolling speed 0.6max mm entry thickness Aluminum Foil Rolling Mill

Specifications

Our aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control systemessure

1 Technical Parameter(aluminum foil rolling mill)



Aluminum alloy	1000,3000,8000 series
Entry thickness	0.6 max mm
Dia. of working roll	200~320 mm
Width of work roller	800~2300mm
Dia. of back up roll	Φ550~850 mm
Width of back-up roller	750~2250 mm
Weight of coil	30000 max kg
Foil rough-rolling thickness	0.05~0.2 mm
Thickness of foil medium-rolling	0.1 mm
Thickness of foil rolling (double sheet)	mm
Rolling speed	2000 max m/min
Exit of Al foil width	700~2080 mm
Rolling form	Non-reversing
Electric control system	SIEMENS  OMRON



2 Our aluminum foil rolling mill have following advantages:



1. Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control system (AGC)

2. Piecewise controlled cooling system .

3. Advanced pre-coated plate filtration system.

4. Automatic and manual controlled CO2 fire extinguishing system.

5. Full digital control and network communication, aim to provide control     accuracy and reliability.

6. Advanced engineering workstations.

7. The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.

8. 12 inch color LCD operator terminals, easy to operate and display.



   We are specialized in the manufacture & installation of aluminum foil rolling mill, meanwhile manufacturing many kinds of auxiliary equipment and aluminum foil rolling mill accessories. We have a strong technical force, advanced production capacity and high quality after-sale service team. What is important is that we can provide you  aluminum foil rolling mill with comfortable price, great after-sale service.

   For more information, please keep in contact with us directly. We hope to receive your detailed inquiries soon, and we are looking forward to cooperating with you in the near future.
