23-Roller Steel Sheet Straightening Machine from direct manufacturer

Specifications

23-Roller Steel Sheet Straightening Machine is of high quality and high performance and high efficiency.





1.Strip parameters:

Yield strength	δs ≤ 260 MPa
width	500-1000mm ,
thickness	0.16-0.8 mm

2.The components of the Straighting Machine

     This leveler consists of : frame, roll cassette, press-down unit, life,

pinch delivery unit, clearance unit, power transmit unit, lubricate system,

hydraulic system and electrical control system.

3.Advanced characters of this Straightening Machine:

 (1)Clearance device can clean upper and lower work rolls surface timing

 to avoid anything attach at strip surface.

 (2) Pinch delivery unit can ensure strip goes into fly shear directly to help

 cross cutting favoring.

 (3) Work roll are driven by constant velocity joint, that CV-joint can ensure work rolls running stably.

 (4)It has no intermediate roll and back up rolls, so it is easy for roll maintenance.













  Should any our products be of your interest , please feel free to contact me, I am ready to provide you any information that you concern. I am looking forward to establishing long term business relationship with you!
