Specifications
Sheet Metal Tension Leveler Line is of higher flatness of the strip shape and higher automation in the operating process.
Metal Sheet Tension Leveler Line
1.Technical parameters
| Aluminum alloy | 1000,3000,8000 series |
| Product thickness | 5~10 mm |
| Rolling force | 6000~25000kn |
| Product width | 800~2200 mm |
| Length of roll surface | 1000~2400 mm |
| Dia. of casting roll | Φ600~Φ1200 mm |
| Max. Coil weight | Max 20000 kg |
| Rolling speed | 800~1500m/min |
| Electric control system | ABB SIEMENS |
2.Specific process
Decoil--enty S roller--straighting machine--exit S roller--recoil.This makes the products meet extensibility requirment finally. When aluminum strip passing through tension leveling line and being leveled,remove the jield point elongation,improve the aluminum mechanic.
3.Advantages
(1) high flatness of strip shape
(2) high automation
(3) convenient operation and installation
4.About our concrete products
Our concrete products include such as Aluminum Casting Machine, Aluminum Cold Rolling Mill, Aluminum Foil Rolling Mill, Tension Leveling Line, Cut-to-length-line, Cast Roll, Cast Roller, Aluminum Cleaning Line and other aluminum-related.
1.Aluminum Casting Machine
2.Aluminum Rotary Shear
3.Aluminum Cold Rollin Mill
4.Aluminum Foil Rolling Mill
5.Tension Leveling Line
6.Cut-to-length-line
7.Coiler Machine
8.Cast Roller and Cast Roller Shell
Should any our products be of interests to you , please feel free to let me know. I am ready to provide you any information about Tension Leveling Line. Welcome to our factory for a visit to inspect our products.
skype id:rosalynduan
qq:1185610798
mobile:008615137182943
