Help CenterSupplying Hydraulic Industrial Rotary Shear Blade Manufacturer
Related Products
-
Supply Rotary Shear For Hot Rolled and Cold Rolled Aluminum PlateNegotiableMOQ: 1 Set -
Hot Sales Plastic Sheet Protective FilmNegotiableMOQ: 2000 Square Meters
-
Hot Sales Aluminum Section Materials With Different Surface Finish Protective FilmNegotiableMOQ: 2000 Square Meters
-
Hot Sales Aluminum Composite Panel With Different Surface Finish Protective FilmNegotiableMOQ: 2000 Square Meters
-
Supply SkimmingNegotiableMOQ: 1 Set
Specifications
Round Shearing Blade Rotary Shears Manufacturer is of high quality, high performance, high efficiency.
1.Technical Parameters:
Shearing Speed |
30--180m/min |
Chuck Diameter |
350--400 |
Chuck Opening Degree |
700--1350mm |
Blade Thickness |
35--40mm |
Blade Material |
6CrW2si |
Blade Shaft Material |
42CrMo |
Shearing Variables |
Min 5mm Max 35mm(unilateral) Max 35mm(unilateral) |
Shearing Steel Strip Thickness |
1.5--5mm |
Blade Overlap Ajustment Precision |
±0.03mm
|
Blade Clearance Adjustment Precision |
±0.005mm |
2.Rotary Shear Units:
Specifications and models |
thickness |
width |
Coil weight |
Finished products width |
Shearing number |
Shearing speed |
2X1600 |
0.3-2mm |
900-1550mm |
30T |
≥40mm |
≤20 |
60m/min |
4X1600 |
0.5-4mm |
900-1550mm |
30T |
≥60mm |
≤13 |
50m/min |
6X1600 |
1-6mm |
900-1550mm |
30T |
≥60mm |
≤10 |
40m/min |
8X1800 |
2-8mm |
900-1800mm |
30T |
≥70mm |
≤6 |
30m/min |
10X2000 |
3-10mm |
900-2000mm |
30T |
≥80mm |
≤5 |
25m/min |
12X2000 |
3-12mm |
900-2000mm |
30T |
≥100mm |
≤5 |
20m/min |
3.Patents our Rotary Shears have got:
Change blades swiftness patent
Wide strip edge cutting patent
4.Our concrete products
Our concrete products include such as Aluminum Casting Machine, Aluminum Cold Rolling Mill, Aluminum Foil Rolling Mill, Tension Leveling Line, Cut-to-length-line, Coiling Machine, Recoiling Machine, Straightening Machine, Rotary Shear and Cast Roller Series.
Should any of our concrete products be of your interest, please feel free to contact me, I am ready to provide you any information that you concern. I am looking forward to establishing long term business relationship with you!
