Specifications
The Flying Shearing Line is of high quality and high preciaion.It is continuous and automatic.1. Technical parameters of Flying Shearing Line
| Material | aluminum and its alloy |
| Strip thickness | 0.3~12 mm |
| Strip width | 600~2150 mm |
| Weight of entry coil | 5000~25000 kg |
| Width of cutting | 550~2100 mm |
| Length of cutting | 600~6000 mmm |
| Stacking sheet height | 500 mm |
| Line speed | 60~100 m/min |
| Frenquency of cutting | 10 times/min |
2. Main Features of Flying Shearing Line
(1)The series aluminum coil flying shearing line is for the metal rolling plate after coiling, leveling, fixed length, cutting into the required length flat and stacking.
(2) It is suitable fo processing colded-rolled and hot-rolled various metal material
(3)consists of uncoiler,leveling system,feeding system,cutting system,conveying system,stacking system.
3 Advantages of Flying Shearing Line
(1) high reliability and high accurancy
(2) continuous production without stopping because of flying shear
(3) no scratches and marks on the sheet surface after cutting
For more information, please keep in contact with me directly. We hope to receive your detailed inquiries soon, and we are looking forward to having the chance of cooperating with you in the near future.
