Specifications
Cut to length line(cutting machine)1,Fully automatic
2,Easy to operate
3,ISO9001:2008
4,Good after-sale service
detailed information
The cut to length line is used to shear the metal plate,after uncoiling, leveling, scaling, into flat sheet and stack. It is suitable to process cold rolled and hot rolled carbon steel, silicon steel, tinplate, stainless steel and surface plating after all kinds of metal material with the surface plated by film.The cut to length line is mainly composed of coil car, uncoiler, leveling machine, conveying machine, cutting plate machine, storage processing, and other groups.The line can be used with the slitting machine, which can cut sheet metal into shape with the right width and right length and stack the productions.
Technical parameter
Material |
aluminium and its alloy |
Stripthckness |
0.3--12mm |
Stripwidth |
600--2150mm |
Weigh of entry coil |
5000--25000kg |
Width of cutting |
550--2100mm |
Length of cutting |
500--6000mm |
Stacking sheet height |
500mm |
Line speed |
60--100m/min |
Frequency of cutting |
10times/min |
Advantage
1.It is high-performance product integrating machine, electricity,and liquid together.
2.A high degree of automation, simple operation and reliable.
3.Fixed length accuracy, high plate flatness
4.Device configuration is decided by the customers' needs
5.Processing and assembling of basic pieces is high precision, with maximum equipment service life
Major Units and flow
Our company is specialized in manufacturing & installing aluminum equipment. We can also undertake the design and manufacture of other non-ferrous metal equipment. Our concrete products include such as cold rolling mill, aluminum cast rolling mill , aluminum foil rolling mill, tension leveler line, cut to length line, aluminum cleaning line ,cast roll, cast roller, steel sleeve, aluminum-related. We can undertake the mechanical, hydraulic & electrical upgrading of the above equipment.
Compony development
Strategic partners
main product
Quality control
Product certification
down-stream product
Why us?
1.we have We have professional engineers to help you design your machines.
2.We take care of your orders and ensure the quality.
3.reasonable price and good corporate image
4.Experience in international cooperation
1.We have technical team to provide technical advice,confirm customer's needs and offer complete solutions.
2.We have professional experience in the design,manufacture and installation of machines.
For more information, please contact us directly. We hope to receive your detailed inquiries soon, and we are looking forward to having the chance of cooperating with you in the near future.
