Aluminum Foil Rolling Mill
1.Speculations Of Aluminum foil roiling mill
(1). Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control system (AGC).
(2). Piecewise controlled cooling system .
(3). Advanced pre-coated plate filtration system.
(4). Automatic and manual controlled CO2 fire extinguishing system.
(5). Full digital control and network communication, aim to provide control accuracy and reliability.
(6). Advanced engineering workstations.
(7). The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.
(8). 12 inch color LCD operator terminals, easy to operate and display.
Technical Parameter
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 0.6 max mm |
Dia. of working roll | 200~320mm |
Width of work roller | 800~2300mm |
Dia. of back up roll | Φ550~850mm |
Width of back-up roller | 750~2250mm |
Weight of coil | 30000 max kg |
Foil rough-rolling thickness | 0.40~0.012mm |
Thickness of foil rolling(double sheet) | 0.1~0.006mm |
Rolling speed | 2000 max m/min |
Exit of AL foil width | 700~2080 mm |
Rolling form | Non-reversing |
ABB electric control system | SIMENS OMRON |
Send Inquiry to This Supplier
