4 hi Irreversible Aluminum Foil Rolling Mill

4 hi Irreversible Aluminum Foil Rolling Mill photo-1
US$ 500,000 - 700,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, foil rolling mill
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, foil rolling mill
Place of Origin Henan, China
Brand Name HZZG
Model Number 280/800/1850
Certification ISO9001:2008
Warranty 1 YEAR
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. used in aluminum industry
2. hydraulic system
3.best price
4.high quality



FAQ

 1.What is the usual entry thickness ?

   max.0.6mm

2.what is your machine's roolling form ?

  non-reversing

3.what is the machine electric control model ?

 SIEMENS OMRON

4.what is the finished product ?

0.1-0.006mm aluminum foil





Company Information



   Zhengzhou Hengzhong Heavy Machinery Manufacturing Co.,Ltd. is an aluminum processing company which integrates the design,manufacture and installation. We have more than 10 years of experience in manufacturing the whole set of aluminum processing quipment and we starts the international trading since 2008. As one of the out-standing manufacturing industry, our quality and technology are guaranteed, our service is also out-standing, the most important is that we can give you a turn-key solution from the very beginning of setting up the production line.



    Our certification:





    Our concrete products include aluminum casting mill, aluminum cold rolling mill, melting furnace, standing furnace, cut-to-length-line, aluminum foil rolling mill, slitting machine , aluminum cleaning line.

4 hi irreversible Aluminum Foil Rolling Mill





Our Services





  We have strong technical force, advanced production capacity and high research ability. There is the independent afer-sale service team set in our company, any question about the aluminum production line and installation can be solved by the technical personnel. As we are the direct manufacturer , the quality is guaranteed and the price is more competitive than other suppliers.



Packaging & Shipping

    The Machines will be in standard exporting package, it usually in wooden case, water-proof package.If there are other specific package requirements from the clients, it will also be well satisfied.



4 hi irreversible Aluminum Foil Rolling Mill





1. the technical parameters:

Aluminum alloy

1000,3000,8000 series

Entry thickness

0.6 max mm

Dia. of working roll

200~320 mm

Width of work roller

800~2300mm

Dia. of back up roll

Φ550~850 mm

Width of back-up roller

750~2250 mm

Weight of coil

30000 max kg

Foil rough-rolling thickness

0.05~0.2 mm

Thickness of foil medium-rolling

0.1 mm

Thickness of foil rolling (double sheet)

mm

Rolling speed

2000 max m/min

Exit of Al foil width

700~2080 mm

Rolling form

Non-reversing

Electric control system

SIEMENS  OMRON

2,Our aluminum foil rolling mill have following advantages:

A. Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control system (AGC).

B. Piecewise controlled cooling system .

C. Advanced pre-coated plate filtration system.

D. Automatic and manual controlled CO2 fire extinguishing system.

E. Full digital control and network communication, aim to provide control accuracy and reliability.

F. Advanced engineering workstations.

G. The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.

H. 12 inch color LCD operator terminals, easy to operate and display.

              We are specialized in the design, manufacture & install of aluminum foil rolling mill, we supply kinds of auxiliary equipment and aluminum foil rolling mill accessories. We have a strong technical force, advanced production capacity and high quality after-sale service team. We can provide you product with comfortable price, great after-sale service.

     4 hi irreversible Aluminum Foil Rolling Mill

       Should any of our products be of your interest, please feel free to contact me, i am looking forward to establishing business relationship with you. Wecome inquiry here and welcome to our factory for a visit.
