Specifications
aluminum foil rolling mill1.Mix product thickness 0.006mm
2.Full automatic
3.SIEMENS Electric control system
Supply high quality aluminum foil rolling mill
aluminum foil rolling mill / aluminum foil / foil rolling mill / foil rolling machine
Technical Parameters of Aluminum Foil Rolling Mill
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 0.6 max mm |
Dia. of work roll | 200~320 mm |
Width of work roller | 800~2300 |
Dia. of back up roll | Φ550~850 mm |
Width of back-up roller | 750~2250 mm |
Weight of coil | 30000 max kg |
Foil rough-rolling thickness | 0.05~0.2 mm |
Thickness of Foil medium-rolling | 0.1 mm |
Thickness of foil rolling (double sheet) | 0.1~0.06mm |
Rolling speed | 2000 max m/min |
Exit of Al foil width | 700~2080 mm |
Rolling form Non-reversing | Non-reversing |
ABB Electric control system | SIEMENS OMRON |
Brief Introduction of Aluminum Foil Rolling Mill
Our aluminum foil rolling mill is an equipment which can roll aluminum plate coil with entry thickness under 0.5mm into aluminum foil with thickness more than 2x0.006mm after several times of rolling.
This machine is mainly used for aluminum foil rolling, processing and refining.
Advantages of Aluminum Foil Rolling Mill
A. Aluminum foil rolling mill has an advanced hydraulic pressure on the thickness of the automatic control
system (AGC).
B. Piecewise controlled cooling system .
C. Advanced pre-coated plate filtration system.
D. Automatic and manual controlled CO2 fire extinguishing system.
E. Full digital control and network communication, aim to provide control accuracy and reliability.
F. Advanced engineering workstations.
G. The roller bearing of aluminum foil rolling mill use a four-row cylindrical roller bearings and oil mist lubrication.
H. 12 inch color LCD operator terminals, easy to operate and display.
Aluminum foil processing line
aluminum foil rolling mill / aluminum foil / foil rolling mill / foil rolling machine
